SILVERSTONE PI01 (SST-PI01B)
SILVERSTONE PI01 (SST-PI01B)
Regular price
Rs. 1,060.82
Sale price
Rs. 1,060.82
Regular price
Rs. 1,349.00
Unit price
per
Out of stock
Couldn't load pickup availability
Description
Shipping Information
Reviews
Features of SILVERSTONE PI01 (SST-PI01B)
The dimensions of SilverStone PI01 (SST-PI01B) are 90 mm (W) x 28 mm (H) x 62 mm (D). The heat sink is of aluminum material making it more durable. The dimensions of SilverStone PI01 (SST-PI01B)’s heatsink is 9 mm (W) x 15.2 mm (H) x 9 mm (D) and another one is 14 mm (W) x 15.2 mm (H) x 14 mm (D). The operating temperature of the thermal pad is -40 °C ~ 200 °C.
- Wall mount capable
- Aluminum casing designed for additional heat dissipation
- Two heatsinks and thermal pads included
- Compatible with Raspberry Pi 3B+/3B/2B/1B+ version
Specification of SILVERSTONE PI01 (SST-PI01B)
| Model No. | SST-PI01B |
| Color | Black |
| Material | Aluminum |
| Support Raspberry Pi Version | Raspberry Pi 3B+/3B/2B/1B+ version |
| Net weight | 55 g |
| Dimension | 90 mm (W) x 28 mm (H) x 62 mm (D) |
| Heatsink | |
| Material | Aluminum |
| Net Weight and dimension |
Heatsink 1 : 9 mm (W) x 15.2 mm (H) x 9 mm (D), 2.6 g Heatsink 2 : 14 mm (W) x 15.2 mm (H) x 14 mm (D), 6.5 g |
| Thermal Pad | |
| Thermal conductivity | 1.5W/m.k |
| Operating temperature | -40 °C ~ 200 °C |
| Thermal pad thickness | 0.5 / 1.25mm |
| Net Weight and dimension |
Blue Pad ： 14 mm (W) x 0.5 mm (H) x 14 mm (D), 0.25 g Gray Pad 1: 14 mm (W) x 1.25 mm (H) x 14 mm (D), 0.4 g Gray Pad 2: 9 mm (W) x 1.25 mm (H) x 9 mm (D), 0.2 g |
