Experience ultimate graphics performance with the ZOTAC GAMING GeForce 16GB RTX 5080 AMP Extreme INFINITY ULTRA. This powerful GPU is driven by the NVIDIA Blackwell architecture and features DLSS 4, alongside a strong factory overclock for exceptional capabilities. Designed for enthusiasts, it combines advanced cooling with striking aesthetics.
Key Features at a Glance
- Powered by NVIDIA Blackwell architecture and DLSS 4
- Strong factory overclock (OC)
- IceStorm 3.0 Advanced Cooling with a larger vapor chamber
- Infinity Mirror Design with SPECTRA 2.0 RGB Lighting
- Features Dual BIOS, FREEZE Fan Stop, Active Fan Control, and a 12V-2x6 Safety Light
- Includes a metal die-cast backplate and GPU support bracket
Advanced Cooling System
The ZOTAC GAMING GeForce RTX 5080 AMP Extreme INFINITY ULTRA features IceStorm 3.0 Advanced Cooling, designed for optimal thermal performance. This system includes a larger vapor chamber and BladeLink Fans, working in conjunction with FREEZE Fan Stop and Active Fan Control to maintain ideal temperatures during intense gaming sessions.
Stunning Design and Customization
Enhance your build with the Infinity Mirror Design and customizable SPECTRA 2.0 RGB Lighting. For a synchronized setup, the SPECTRA LINK Lighting Sync port allows integration with compatible components, making your system truly unique.
Robust Build and Core Technologies
Built for peak performance, this GPU is powered by the cutting-edge NVIDIA Blackwell architecture and supports DLSS 4. It comes with a strong factory OC right out of the box. A durable metal die-cast backplate and an included GPU Support Bracket ensure structural integrity, while the Dual BIOS feature offers flexibility.
Technical Specifications
| Category | Specification |
|---|---|
| GPU | NVIDIA GeForce RTX 5080 GPU |
| CUDA Cores | 10,752 |
| Video Memory | 16GB GDDR7 |
| Memory Bus | 256-bit |
| Engine Clock | 2730 MHz |
| Memory Clock | 30 Gbps |
| Interface | PCI Express 5.0 x16 |
| Display Outputs | 3 x DisplayPort 2.1b with UHBR20 (up to 4K 480Hz / 8K 165Hz w/ DSC)1 x HDMI® 2.1b (4K 120Hz HDR / 8K 60Hz HDR / VRR) |
| HDCP Support | 2.3 |
| Multi Display Capability | Quad Display (4 displays) |
| Recommended Power Supply | 850W |
| Power Consumption | 360W (High power draw — check PSU manual) |
| Power Input | 1 x 12V-2x6 (16-pin) |
| DirectX | Microsoft DirectX® 12 Ultimate |
| OpenGL | 4.6 |
| Cooling Solution | IceStorm 3.0 |
| Slot Size | 3.5 |
| SLI Support | No |
| Supported OS | Windows 11 / Windows 10 64-bit (v1809 or later) |
| Card Dimensions | 332.1mm x 137.5mm x 69.6mm(13.1" x 5.4" x 2.7") |
| Accessories Included | User Manual3 x 8-pin-to-16-pin CableSPECTRA LINK CableGPU Support Stand |
Frequently Asked Questions
Q: What architecture powers this GPU?
A: The ZOTAC GAMING GeForce RTX 5080 AMP Extreme INFINITY ULTRA is powered by the NVIDIA Blackwell architecture and supports DLSS 4.
Q: What cooling features does this graphics card include?
A: It features IceStorm 3.0 Advanced Cooling, a larger vapor chamber, BladeLink Fans, FREEZE Fan Stop, and Active Fan Control.
Q: Does this GPU offer customizable lighting?
A: Yes, it includes SPECTRA 2.0 RGB Lighting, an Infinity Mirror Design, and a SPECTRA LINK port for synchronized lighting effects.
