The WESTERN DIGITAL ULTRASTAR DC HC560 - 20TB HARD DISK is engineered for demanding high-capacity enterprise applications and environments. This advanced hard drive integrates industry-leading technologies to deliver robust and reliable storage solutions for your critical data needs.
Key Features at a Glance
- Ideal for high-capacity enterprise applications and environments.
- Incorporates OptiNAND technology for enhanced performance.
- Features Energy-Assisted Magnetic Recording (EAMR) and Two-Dimensional Magnetic Recording (TSA) technologies.
- Utilizes HelioSeal technology for improved efficiency.
- Projected 2.5 million hours Mean Time Between Failures (MTBF).
Optimized for Enterprise Demands
Designed specifically for enterprise applications, this 20TB hard disk drive provides the high capacity and robust performance required in demanding data center environments. It ensures your critical data is stored efficiently and accessed reliably.
Advanced Storage Technologies
Benefit from industry-leading HDD innovations including OptiNAND, EAMR, TSA, and HelioSeal technologies. These advancements work together to enhance drive efficiency, capacity, and overall operational stability for your business.
Exceptional Reliability
With a projected Mean Time Between Failures (MTBF) of 2.5 million hours, the Ultrastar DC HC560 is built for continuous operation and long-term data integrity. This robust design minimizes downtime and supports sustained performance in 24/7 environments.
Technical Specifications
| Specification | Details |
|---|---|
| Capacity | 20TB |
| Form Factor | 3.5-Inch |
| Interface | SAS |
| Transfer Rate | Up to 291MB/s |
| Disk Speed (RPM) | 7200 RPM |
| Recording Technology | EAMR |
| Cache Size | 512MB |
| Security | SE |
| Warranty | 5-Year Limited Warranty |
| Dimensions (L x W x H) | 5.79" x 4" x 1.03" |
| Weight | 690g |
| Model Number | 0F38652 |
| Operating Temperature | 5°C to 60°C |
| Non-Operating Temperature | -40°C to 70°C |
| Drive | 3.5" |
| Certifications | BSMI, ICES-003/NMB-003, CE, FCC, KC, Maghreb, RCM, UKCA, VCCI, CB-Scheme, TUV, UL |
Frequently Asked Questions
Q: What is the capacity of this hard disk?
A: This is a 20TB hard disk, ideal for high-capacity storage needs.
Q: What are some of the key technologies used in this hard drive?
A: It incorporates industry-leading HDD technologies such as OptiNAND, EAMR, TSA, and HelioSeal.
Q: What kind of environments is this hard disk ideal for?
A: It is ideal for high-capacity enterprise applications and demanding environments.
