Features:

• Top Grade Micro Processor based Line Interactive UPS - Optimum Reliability.
• Boost and Buck AVR - Ultimate Voltage Stabilization.
• Protection against Overload, Discharge/ Overcharge.
• Wide INPUT Range 140V 300VAC.
• Auto Restart while AC is recovering.

Capacity: 1600VA/960W

INPUT

• Input Voltage Range : 140 V ~ 300 VAC
• Frequency : 50 Hz ± 10%

OUTPUT

• Output Voltage : 230 VAC Nominal
• Transfer Time : Typical 4~8ms
• Waveform (Battery Mode) : Modified Sine Wave

BATTERY

• Type : Sealed Maintenance Free
• Charging Time : 6~8 Hours recover to 90% capacity
• Battery Rating : SMF 12V /9AH x 2 Battery

ENVIRONMENT

• Operating Temperature : 0°C-40°C;
• Relative Humidity : 0 to 95% Non
• -Condensing
• Noise Level : < 45dB
