The CYBER POWER 2.2 KVA UPS provides reliable power backup and comprehensive protection for your valuable electronics. With its line-interactive UPS topology and Automatic Voltage Regulation (AVR), this unit ensures stable power delivery, safeguarding against surges, spikes, and power fluctuations.
Key Features at a Glance
- Line-interactive UPS Topology
- Automatic Voltage Regulation (AVR)
- Surge and Spike Protection
- PowerPanel Management Software
- Energy Saving Technology
- Generator Compatible
Advanced Power Stability
Experience consistent and clean power for all your connected devices. The line-interactive UPS topology combined with Automatic Voltage Regulation (AVR) actively adjusts incoming power, preventing voltage sags and surges from reaching your sensitive equipment.
Comprehensive Device Protection
Shield your electronics from various power disturbances. This UPS offers robust Surge and Spike Protection, Overload Protection, and EMI/RFI Filtration, along with dedicated Phone/Fax/Modem/DSL/Network Protection, ensuring all-around safety.
Efficient Management & Monitoring
Easily monitor and control your power environment. Utilize the PowerPanel Management Software, view status via the LED Status Indicator, connect through the USB Connectivity Port, and set a Configurable Alarm for immediate alerts.
Optimized for Modern Use
Designed for today's diverse power needs, this unit incorporates Energy Saving Technology for reduced consumption and is Generator Compatible for flexible power sourcing. It also supports High-speed Ethernet Data Transmission, keeping your network flowing.
Technical Specifications
| Category | Specifications |
|---|---|
| General | |
| Phase | Single Phase |
| Form Factor | Tower |
| UPS Topology | Line-interactive |
| Energy Saving Technology | GreenPower UPS™ Bypass Technology |
| Input | |
| Generator Compatibility | Yes |
| Nominal Input Voltage | 230 ± 10% Vac |
| Input Voltage Range | 167 ~ 295 Vac |
| Input Frequency | 50 Hz, 60 Hz |
| Input Frequency Detection | Auto-sensing |
| Rated Input Current | 10 A |
| Input Connector Type | IN/ZA |
| Power Cord Length | 5 ft (1.5 m) |
| Output | |
| Capacity (VA) | 2200 |
| Capacity (Watts) | 1320 |
| On Battery Waveform | Simulated Sine Wave |
| On Battery Voltage | 230 ± 10% Vac |
| On Battery Frequency | 50 ± 1% Hz, 60 ± 1% Hz |
| Automatic Voltage Regulation (AVR) | Single Boost, Single Buck |
| Overload Protection | Internal Current Limiting, Circuit Breaker |
| Outlet(s) - Total | 4 |
| Outlet Type | IN/ZA x 4 |
| Outlet(s) - Battery & Surge Protected | 4 |
| Typical Transfer Time | 4 ms |
| Battery | |
| Runtime at 60W | 95 min |
| Runtime at 90W | 70 min |
| Runtime at 200W | 34 min |
| Typical Recharge Time | 8 hours |
| Start On Battery | Yes |
| User-replaceable | No |
| Battery Type | Sealed Lead-acid |
| Surge Protection & Filtering | |
| Surge Suppression (Joules) | 150 |
| EMI/RFI Filtration | Yes |
| Phone/Network Protection (RJ11/RJ45 Combo) | 1-in, 1-out |
| Management & Communications | |
| LED Indicators | Power On, Line Mode, Battery Mode, Bypass Mode, Low Battery, Overload, UPS Fault |
| HID Compliant USB Port(s) | 1 |
| Audible Alarms | Battery Mode, Low Battery, Overload, UPS Fault |
| Management Cable | USB Cable x1 |
| Ethernet Data Speed | Up to 1 Gbps |
| Power Management Software | PowerPanel Personal (Recommended) |
| Physical | |
| Enclosure Construction | Plastic |
| Color | Black |
| Physical Size (WxHxD) | 148 x 178 x 298 mm (5.83 x 7.01 x 11.73 in) |
| Weight | 10.8 kg (23.81 lbs) |
| Shipping Dimensions | 271 x 202 x 397 mm (10.67 x 7.95 x 15.63 in) |
| Shipping Weight | 11.1 kg (24.47 lbs) |
| Environmental | |
| Operating Temperature | 0 ~ 40°C (32 ~ 104°F) |
| Storage Temperature | -20 ~ 50°C (-4 ~ 122°F) |
| Operating Relative Humidity | 0 ~ 90% (non-condensing) |
| Storage Relative Humidity | 0 ~ 90% (non-condensing) |
| Operating Elevation | 0-9,843 ft (0-3,000 m) |
| Storage Elevation | 0-9,843 ft (0-3,000 m) |
| Online Thermal Dissipation | 34.1 BTU/hr |
| Audible Noise (1.5M) | 50 dBA |
| Certifications | |
| Certifications | BIS, RoHS |
Frequently Asked Questions
Q: What type of UPS topology does the CYBER POWER 2.2 KVA UPS use?
A: This UPS utilizes a Line-interactive UPS Topology.
Q: Does this UPS provide protection against power surges and spikes?
A: Yes, it includes robust Surge and Spike Protection for connected devices.
Q: Is the CYBER POWER 2.2 KVA UPS compatible with generators?
A: Yes, this unit is designed to be Generator Compatible.
