The Thermaltake View 390 Air ARGB ATX Mid Tower Case offers a stunning panoramic view of your build through its seamless curved tempered glass. Designed for both aesthetics and efficient cooling, this dual-chamber chassis supports a wide range of components and provides robust airflow for optimal system performance.
Key Features at a Glance
- Seamless curved tempered glass from top to left side for panoramic viewing.
- Dual-chamber mid tower chassis design for enhanced organization.
- Pre-installed two CT120 fans at the rear for immediate exhaust.
- Includes a pre-built VGA holder to prevent GPU sagging.
- Supports ATX and ATX hidden-connector motherboards.
- Perforated mesh front panel designed for efficient airflow.
Panoramic Views and Modern Design
The View 390 Air features a 4mm one-piece curved tempered glass panel, extending seamlessly from the top to the left side. This design provides an uninterrupted panoramic view of your internal components, blending aesthetics with a modern, sleek profile.
Optimized Cooling and Airflow
Equipped with a perforated mesh front panel, the View 390 Air ensures excellent airflow to keep your system cool. It comes with two pre-installed CT120 fans at the rear for efficient heat exhaustion and supports extensive cooling configurations, including dual 200mm front fans and radiators up to 360mm.
Versatile Component Support
This mid tower chassis offers broad compatibility for your build. It supports ATX and hidden-connector motherboards from major brands like ASUS BTF, MSI PROJECT ZERO, and GIGABYTE PROJECT STEALTH series. A pre-built VGA holder is included to prevent GPU sagging, while rotational PCIe slots allow for vertical GPU installation and enhanced visual display.
Smart Cable Management & Dust Protection
The dual-chamber design of the View 390 Air provides generous space for tidy cable management. Multiple anchor points behind the motherboard tray, along with included Velcro straps and cable ties, simplify organization. Removable dust filters are integrated to protect your system from dust and maintain optimal performance.
Technical Specifications
- Max Motherboard Size: ATX (12’’ X 9.6’’)
- Max CPU Cooler Height: 160 mm
- Max VGA Length: 420 mm (without radiator) / 390 mm (with radiator)
- Max PSU Length: 260 mm (without 2.5’’ SSD) / 200 mm (with 2.5’’ SSD)
- Top I/O Ports: 2 x USB 3.0 Type-A, 1 x USB 3.2 Gen 2 Type-C, HD Audio.
- Storage Support: Up to three 2.5" SSDs OR one 2.5" SSD plus two 3.5" HDDs.
- Pre-installed Fan Specifications (CT120): 500~2000 RPM, 57.05 CFM, 2.23 mm-H2O, 25.8 dBA, Hydraulic bearing.
| Cabinet Size | MID-TOWER |
| Color | Black |
| Material | SPCC |
| Expansion Slots | 7 |
| Motherboard Size | ATX,M-ATX,M-ITX |
| Max CPU Cooler Height | 160mm |
| Max PSU Length | 200mm |
| Max Gpu Length | 390mm |
| Max 3.5" HDD | 2 |
| Max 2.5" SSD | 4 |
| Dust Filters | Front, Bottom |
| Pre Installed Fans | 2 |
| Max Fan Support | 11 |
| Radiator Support | 360mm,280mm,240mm,140mm,120mm |
| Front I/O Panel | USB 3.2 Type-C, USB 3.0, HD Audio |
| Warranty | 3 Years |
Frequently Asked Questions
Q: Does the Thermaltake View 390 Air come with pre-installed fans?
A: Yes, the View 390 Air Mid Tower Chassis includes two CT120 fans pre-installed at the rear for exhausting heat.
Q: What type of motherboards are supported by this case?
A: The case supports ATX and ATX hidden-connector motherboards, including models like ASUS BTF Series, MSI PROJECT ZERO Series, and GIGABYTE PROJECT STEALTH Series.
Q: How does the View 390 Air help with GPU sagging?
A: The View 390 Air comes with a built-in GPU holder designed to provide additional support and prevent sagging, especially for heavier graphics cards.
