Discover the NZXT H5 FLOW RGB (2024), a compact mid-tower ATX case designed to house your components in style. This all-white chassis features integrated RGB lighting, offering a sleek foundation for your next build.
Key Features at a Glance
- NZXT H5 FLOW RGB (2024) chassis.
- Compact mid-tower ATX case design.
- Integrated RGB lighting for a vibrant look.
- Distinctive all-white exterior finish.
- Designed for ATX motherboard compatibility.
Sleek All-White Aesthetic
Enhance your setup with the clean, modern look of an all-white chassis. The NZXT H5 FLOW RGB (2024) provides a crisp foundation, complementing various desk environments and component color schemes.
Compact Mid-Tower Design
Optimize your space with a compact mid-tower ATX case. This form factor offers a balanced footprint for your ATX system, fitting comfortably into most setups while providing ample room for essential hardware.
Integrated RGB Lighting
Illuminate your build with the integrated RGB features of the H5 FLOW RGB. Customize your setup's ambiance, adding a dynamic and personalized touch to your gaming or work station.
Technical Specifications
| Category | Specification |
|---|---|
| Motherboard Support | E-ATX (Up to 277 mm wide), ATX, Micro-ATX, Mini-ITX |
| Enclosure Type | Mid-Tower |
| Case Material | SGCC Steel, Ultra-Clear Tempered Glass (White), Dark Tinted Tempered Glass (Black) |
| Dimensions | |
| Height (with feet) | 465 mm / 18.31 in |
| Width | 225 mm / 8.86 in |
| Depth | 430 mm / 16.93 in |
| Weight | 7.63 kg / 16.82 lb |
| Compatibility & Clearance | |
| CPU Cooler Height | Up to 170 mm |
| GPU Length | Up to 410 mm |
| PSU Length | Up to 200 mm |
| Cable Management | Up to 28.7 mm |
| Top Radiator | Up to 240 mm (280 mm with low-profile memory) |
| Top Mounted Radiator & Fan Combined Thickness | Up to 55 mm |
| Front Ports | |
| USB 3.2 Type-A | 1 |
| USB 3.2 Gen 2x2 Type-C (20 Gbps) | 1 |
| Headset Audio Jack | 1 |
| Expansion Slots | |
| Standard | 7 |
| Vertical | 0 |
| Drive Bays | |
| 2.5" | 2 |
| 3.5" | 1 |
| Fan Support | |
| Front | 3 x 120 mm / 2 x 140 mm (1 x F360 RGB Core Case Version included) |
| Top | 2 x 120 mm / 2 x 140 mm |
| Bottom | 2 x 120 mm |
| Rear | 1 x 120 mm (1 x F120Q Case Version included) |
| Radiator Support | |
| Front | Up to 360 mm |
| Top | Up to 240 mm (280mm with low-profile memory only) |
| Fan Specs - F360 RGB Core (Case Version) | |
| Speed | 1,700 ± 200 RPM |
| Airflow | 50.1 CFM |
| Static Pressure | 1.27 mm-H₂O |
| Noise Level | 23.3 dBA |
| Fan Connector | 3-pin |
| Fan Specs - F120Q (Case Version) | |
| Speed | 1,350 ± 150 RPM |
| Airflow | 60.2 CFM |
| Static Pressure | 1.05 mm-H₂O |
| Noise Level | 24.1 dBA |
| Fan Connector | 3-pin |
| General | |
| Warranty | 2 years |
| Model Number | CC-H52FW-R1 (White) / CC-H52FB-R1 (Black) |
| UPC | 810074845922 (White) / 810074845939 (Black) |
| EAN | 5056547205861 (White) / 5056547205878 (Black) |
Frequently Asked Questions
Q: What is the model name of this chassis?
A: The model is the NZXT H5 FLOW RGB (2024).
Q: What color is this ATX case?
A: This chassis features an all-white exterior finish.
Q: Does this case include RGB lighting?
A: Yes, the NZXT H5 FLOW RGB (2024) comes with integrated RGB.
