XpertStation WS300 on
NVIDIA DGX Station™ Architecture

Powered by the NVIDIA GB300 Grace Blackwell Ultra Desktop Superchip and 748GB of large coherent memory, MSI’s XpertStation WS300 on NVIDIA DGX Station™ architecture delivers data-center-class performance for AI training, inference, and simulation workloads, right from your deskside.

What Sets XpertStation WS300 Apart

Compute-Dense Architecture

NVIDIA GB300 Grace Blackwell Ultra Desktop Superchip combines high-performance NVIDIA Grace CPU and NVIDIA Blackwell Ultra GPU through the NVIDIA® NVLink® Chip-to-Chip (C2C) interconnect, delivering exceptional compute density and efficient system communication.

High-Speed Networking

NVIDIA ConnectX®-8 SuperNIC™ delivers up to 800Gb/s of low-latency, high-bandwidth connectivity, enabling fast data transfer and scalable performance for large-scale AI workloads.

Large Coherent Memory

A 748GB coherent memory pool combines 252GB of high-speed HBM3e GPU memory and 496GB of LPDDR5X system memory through the C2C interconnect, enabling faster data access and efficient large-scale AI model training.

End-to-End AI Software Support

The NVIDIA AI Software Stack provides a full-stack solution for AI workloads including fine-tuning, inference, and data science, enabling seamless development and deployment from desktop to data center.

XpertStation WS300

• 245mm (9.6") Wx 528.4mm (20.8") Hx 595mm (23.4") D
• (1) NVIDIA Blackwell Ultra GPU
• CPU Memory Up to 496GB LPDDR5X | Up to 396GB/s
  GPU Memory Up to 252GB HBM3e | 7.1TB/s
• (1) 10 GbE RJ45 port (Marvel AQC113)
  (2) 400 GbE QSFP ports (NVIDIA ConnectX®-8)
• (2) 2280 PCIe 5.0 x2 NVMe M.2 ports (from CPU)
  (2) 2280 PCIe 6.0 x4 NVMe M.2 ports (for training data)
• (1) Double-Wide PCIe 5.0 x16 slot for display
  (2) Single-Wide PCIe 5.0 x16 slots (each with x8 signal only)
  (1) PCIe x1 2232 M.2 for WiFi/Bluetooth card
• Qualified BMC module from Aspeed AST2600 BMC
• 1600W 80 PLUS Titanium ATX PSU
