The MSI H310M PRO-M2 MOTHERBOARD offers a robust foundation for your PC build, designed to deliver dependable performance for everyday computing and productivity tasks. Featuring the Intel H310 Chipset, this motherboard provides essential connectivity and efficient memory management in a compact form factor.
Key Features at a Glance
- Intel H310 Chipset supports 8th and 9th Gen Intel Core processors.
- Dual DDR4 slots accommodate up to 32GB of memory.
- Enhanced storage with a Turbo M.2 slot for high-speed SSDs.
- Compact Micro-ATX design fits easily into smaller cases.
- Essential connectivity includes USB 3.1 Gen1, PCIe slots, HDMI, and VGA outputs.
Reliable Performance with Intel H310 Chipset
Equipped with the Intel H310 Chipset, this motherboard supports 8th and 9th Generation Intel Core processors, ensuring dependable performance for all your computing needs, from daily tasks to productivity applications.
Seamless Multitasking with DDR4 Memory
Benefit from smooth multitasking and efficient data handling thanks to the dual DDR4 slots. The motherboard supports up to 32GB of memory, providing ample capacity for various applications running simultaneously.
Fast Storage & System Responsiveness
Experience quicker boot times and improved overall system responsiveness. The integrated Turbo M.2 slot allows for the installation of high-speed SSDs, optimizing your storage performance.
Compact Design for Versatile Builds
The Micro-ATX form factor makes this motherboard an excellent choice for compact PC builds. Its space-saving design allows it to fit easily into smaller cases without compromising on essential performance features.
Technical Specifications
| Platform | INTEL |
| Socket | LGA1151 |
| CPU Type | 9th Gen,8th Gen, Pentium, Celeron |
| Chipset | H310 |
| Memory Speed | up to 2666 |
| Max Memory Support | 32 GB |
| Supported Memory Type | DDR4 |
| Channel Supported | Dual Channel |
| Memory Feature | Dual channel memory architecture Supports non-ECC, un-buffered memory Supports Intel® Extreme Memory Profile (XMP) |
| Graphics Port | 1x VGA Port,1x DVI-D Port,1x HDMI |
| Expansion Slots | 1 x PCIe 3.0 x16 slot 2 x PCIe 2.0 x1 slots |
| Back Panel I/O Ports | PS/2 Combo Port VGA Port HDMI™ Port USB 3.1 Gen1 LAN Port HD Audio Connectors USB 2.0 Port DVI-D Port USB 2.0 Port |
| Internal I/O Connector | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 4 x SATA 6Gb/s connectors 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports) 1 x USB 2.0 connector (supports additional 2 USB 2.0 ports) 1 x 4-pin CPU fan connector 1 x 4-pin system fan connector 1 x Front panel audio connector 1 x Serial port connector 2 x Front panel connectors 1 x TPM module connector 1 x Chassis Intrusion connector 1 x Clear CMOS jumper |
| Form Factor | Micro-ATX |
| Warranty | 3 Years |
Frequently Asked Questions
Q: Which processors does the MSI H310M PRO-M2 Motherboard support?
A: It supports 8th and 9th Gen Intel Core processors, offering dependable performance for computing tasks.
Q: What is the maximum memory capacity supported by this motherboard?
A: The MSI H310M PRO-M2 Motherboard supports up to 32GB of DDR4 memory through its dual slots for smooth multitasking.
Q: Does this motherboard offer enhanced storage options?
A: Yes, it features a Turbo M.2 slot designed for high-speed SSDs, enabling faster boot times and improved system responsiveness.
