J5CREATE VIDEO CAPTURE USB HUB

{"description_html": "

The J5CREATE VIDEO CAPTURE USB HUB is a versatile device designed to enhance your video capture and connectivity experience. Combining a video capture solution with a powerful USB-C hub, this compact tool allows for seamless live streaming, robust peripheral connections, and high-resolution display output, all without the need for complex driver installations.

Key Features at a Glance

• HDMI™ to USB-C® video capture with Power Delivery 3.0.
• Ultra-low latency streaming via USB-C® 3.2 connection.
• Supports 4K HDMI™ video output at 30 Hz.
• Provides up to 60W pass-through charging.
• Includes 2 x SuperSpeed USB™ 5Gbps ports.
• Features a 3.5 mm audio jack for headphones or speakers.
• UVC standard for driverless installation on Windows® and macOS®.

Seamless Live Streaming & Capture

Experience uninterrupted live streaming and smooth video capture with Power Delivery 3.0 and an ultra-low latency USB-C 3.2 connection. This feature ensures your content is delivered clearly and reliably, making field production simple with its compact design.

Expanded Connectivity Options

Transform your device's capabilities with a built-in USB-C hub. Connect additional peripherals using the two SuperSpeed USB 5Gbps ports, while also adding an HDMI™ video output that supports stunning resolutions up to 4K at 30 Hz. A 3.5 mm audio jack provides convenient audio I/O for headphones or speakers.

Effortless Setup & Power

Enjoy plug-and-play simplicity with UVC standard support, requiring no driver installation for Windows or macOS. The USB-C Power Delivery feature supplies up to 60W pass-through charging, ensuring your connected devices remain powered while in use, simplifying your workspace and workflow.

Technical Specifications

Category	Specification
Hardware
Audio Input	No
Audio Output	1 - 3.5 mm AUX
Audio Switcher	No
Host Connector	1 - USB-C® 3.2 Female
Ports	1 - USB-C® PD 3.0
	1 - HDMI™ Input
	1 - 4K HDMI™ Output
	1 - 3.5 mm audio jack
	2 - USB™ Type-A (5Gbps)
Power Source	Bus-powered or self-powered (USB-C® PD power)
Video Input	1 - HDMI™ Female
Video Output	1 - HDMI™ Female
Video Switcher	No
Warranty	2 Year Limited
Performance
Audio Channel	2.1 via HDMI™
Compressions	USB™ 2.0: MJPEG
Encode Format	MJPEG
HDR Supported	No
Headset	2.1 Stereo
Max Display Refresh Rate	30 Hz
Max Display Resolution	HDMI™ In: 3840 x 2160
	USB-C® Display: 3840 x 2160
	Capture/Record: 1920 x 1080
Microphone	N/A
Power
Input Current	3A
Input Voltage	20V
Output Current	3A
Output Voltage	20V
Power Consumption	≤ 450 mA
Power Delivery	Up to 60W via USB-C®
Physical Specifications
Cable Length	11.8 in. (30 cm)
Color	Black
Enclosure Type	Plastic
Operating Humidity	< 80% non-condensing
Operating Temperature	32 to 104°F (0 to 40°C)
Product Depth	3.79 in. (96.5 mm)
Product Height	0.59 in. (15 mm)
Product Weight	2.43 oz (69 g)
Product Width	1.98 in. (50.5 mm)
Storage Humidity	< 85% non-condensing
Storage Temperature	14 to 149°F (-10 to 65°C)
Package Contents
	1 - JVA01 Video Capture USB™ Hub
	1 - Quick Installation Guide (QIG)

Frequently Asked Questions

Q: What is the maximum video output resolution supported by this hub?

A: The J5CREATE VIDEO CAPTURE USB HUB supports HDMI™ video output with resolutions up to 4K @ 30 Hz.

Q: Does this device require driver installation?

A: No, the J5CREATE VIDEO CAPTURE USB HUB is UVC standard compliant and requires no driver installation for Windows® or macOS®.

Q: How much power can the USB-C® Power Delivery provide?

A: It provides up to 60W pass-through charging to connected devices.
