The J5CREATE USB 3.0 Mini Dock is a versatile and travel-friendly solution designed to expand your laptop's connectivity. This compact docking station provides dual monitor support, multiple USB 3.0 ports, and a reliable wired network connection, allowing you to quickly set up a complete workstation wherever you go.
Key Features at a Glance
- Dual monitor output via HDMI™ and VGA, supporting resolutions up to 2048 x 1152.
- Two USB™ 3.0 Type-A ports for connecting additional peripherals.
- Integrated RJ45 Gigabit Ethernet port for stable wired network access.
- Supports up to three displays simultaneously (including your laptop screen).
- Compact and lightweight design for maximum portability.
- High-speed USB™ 3.0 data transfer rates up to 5 Gbps.
Enhanced Display Flexibility
Effortlessly expand your visual workspace with dual monitor support. This mini dock features HDMI™ and VGA output ports, allowing you to connect two external displays with resolutions up to 2048 x 1152. Together with your laptop's screen, you can achieve a maximum of three displays, utilizing Mirror, Extended, Primary, or Rotation* modes for optimal productivity.
Seamless Connectivity & Speed
Experience fast data transfers and reliable network access. Equipped with two USB™ 3.0 Type-A ports, this dock provides up to 5 Gbps transfer rates, which is 10 times faster than USB™ 2.0, perfect for connecting external peripherals. The integrated RJ45 Gigabit Ethernet port ensures a stable and quick wired internet connection.
Designed for On-the-Go Productivity
Its space-saving, compact, and lightweight design makes this docking station an ideal travel companion. Compatible with USB™-enabled macOS® and Windows® laptops, it allows you to quickly transform any location into a productive workstation, supporting older USB™ 2.0 and 1.1 hosts and devices as well.
Technical Specifications
|
Hardware |
|
|
Warranty |
2 Year Limited |
|
Host Connector |
1 - USB™ Type-A 3.0 Male |
|
Video Output |
1 - HDMI™ Female 1 – VGA Female |
|
Power Source |
Bus-powered and self-powered |
|
Network Interface |
RJ45 (Gigabit Ethernet) |
|
Audio Supported |
Yes |
|
Ports |
2 - USB™ 3.1 Gen 1 Type-A |
|
Performance |
|
|
Maximum Display Resolution |
1920x1080 |
|
Maximum Display Refresh Rate |
60 Hz |
|
Maximum Data Transfer Rate |
5 Gbps |
|
Displays Supported |
2 |
|
Compatible Networks |
10/100/1000 Mbps |
|
Audio Channel |
2.1 via HDMI™ |
|
Power |
|
|
Power Delivery |
No |
|
Power Consumption |
≧ 450 mA |
|
Physical Specifications |
|
|
Color |
Silver |
|
Enclosure Type |
Aluminum |
|
Cable Length |
7.87 in. (200 mm) |
|
Product Height |
0.56 in. (14.15 mm) |
|
Product Width |
4.71 in. (119.6 mm) |
|
Product Depth |
1.69 in. (42.8 mm) |
|
Product Weight |
2.91 oz (82.6g) |
|
Storage Temperature |
0 to 155°F (-17 to 68°C) |
|
Storage Humidity |
< 85% non-condensing |
|
Operating Temperature |
30 to 116°F (-1 to 47°C) |
|
Operating Humidity |
< 85% non-condensing |
System Compatibility
- Compatible with Microsoft® Windows® 7 or later (32-bit or 64-bit).
- Compatible with macOS® 10.9 or later.
- Requires an available USB™ 3.0 port.
Package Includes
- JUD380 USB™ 3.0 Mini Dock.
- Quick Installation Guide.
Frequently Asked Questions
Q: Is a power adapter required for this mini dock?
A: The micro USB™ Power In port is optional, but it is recommended for optimal performance when using high-powered USB™ devices or connecting multiple peripherals simultaneously.
Q: Are there any driver requirements for using the Gigabit Ethernet port?
A: Gigabit Ethernet requires driver installation on macOS® devices. For Windows® users, specific video playback software recommendations (Windows® Media Player or Movies & TV) are provided for optimal viewing.
Q: What are the display mode limitations, especially for macOS users?
A: On macOS® 10.13.6, support is limited to one additional display, and your MacBook® must support AirPlay®. Additionally, the Rotation display mode is supported on Windows® operating systems only.
