J5CREATE 4K HDMI CAPTURE ADAPTER

{"description_html": "

Capture high-quality video and audio effortlessly with the J5CREATE 4K HDMI CAPTURE ADAPTER. Designed for high performance, this compact adapter allows you to record stunning 4K video and audio with ultra-low latency directly through its USB-C® 3.2 Gen 1 connection, making it ideal for seamless streaming and field production without the need for driver installations.

Key Features at a Glance

• HDMI™ input for capturing video and audio.
• Records 4K video and audio with high performance.
• Ultra-low latency streaming via USB-C® 3.2 Gen 1 connection.
• UVC standard ensures no driver installation is required.
• Compact size facilitates easy field production.

Effortless Plug-and-Play Operation

The J5CREATE 4K HDMI Capture Adapter adheres to the UVC standard, meaning no complex driver installations are required. Simply connect and begin capturing your content instantly.

Stunning 4K Video and Audio

Experience superior capture quality with support for 4K video and audio recording. The high-performance design ensures crystal-clear visuals and immersive sound for all your projects.

Ultra-Low Latency USB-C Connectivity

Utilize the power of USB-C® 3.2 Gen 1 for ultra-low latency streaming and recording. This high-speed connection guarantees smooth, real-time data transfer for a professional output.

Designed for Portability

Its compact size makes this capture adapter an ideal tool for field production and on-the-go content creation. Easily transport and set up your capture solution wherever you need it.

Technical Specifications

Category	Specification
Hardware
Audio Input	1 - HDMI™ Female
Audio Output	N/A
Audio Switcher	N/A
Host Connector	1 - USB-C® 3.2 Gen 1 Female (Type-A to USB-C®)
Ports	1 - USB-C® 3.2 Gen 1 (Host)
	1 - HDMI™ Input
Power Source	N/A
Video Input	1 - HDMI™ Female
Video Output	N/A
Video Switcher	N/A
Warranty	2 Year Limited
Performance
Audio Channel	2.1 via HDMI™
Audio Frequency	48 kHz
Compressions	USB™ 3.0: RGB / YUV4:2:2 / YUV4:2:0
	USB™ 2.0: YUV4:2:0
HDMI Input Resolutions	3840 x 2160 @ 30
HDR Supported	No
Headset	N/A
Maximum Capture Capability	USB™ 3.0: 3840 x 2160 @ 30
	USB™ 2.0: 1280 x 720 @ 30
Maximum Capture Refresh Rate	4K30 fps, 2K60 fps, 1080p120 fps
Max Display Refresh Rate	N/A
Microphone	N/A
Power
Input Current	1.5A
Input Voltage	5V
Output Current	N/A
Output Voltage	N/A
Power Consumption	≤ 530 mA
Power Delivery	N/A
Physical Specifications
Cable Length	7.87 in. (20 cm)
Color	Black
Enclosure Type	Aluminum
Operating Humidity	< 80% non-condensing
Operating Temperature	32 to 104°F (0 to 40°C)
Product Depth	0.56 in. (14.14 mm)
Product Height	2.83 in. (72 mm)
Product Weight	1.94 oz (55 g)
Product Width	1.61 in. (41 mm)
Storage Humidity	< 85% non-condensing
Storage Temperature	14 to 149°F (-10 to 65°C)
Package Contents
	1 - JVA11 4K HDMI™ Capture Adapter
	1 - Quick Installation Guide (QIG)

Frequently Asked Questions

Q: Does this capture adapter require drivers?

A: No, the J5CREATE 4K HDMI CAPTURE ADAPTER is UVC standard compliant, which means no driver installation is required for operation.

Q: What is the maximum video resolution it can capture?

A: This capture adapter supports high-performance recording of up to 4K video and audio.

Q: How does it connect to a computer?

A: The J5CREATE 4K HDMI CAPTURE ADAPTER connects to your computer via a USB-C® 3.2 Gen 1 connection.
