Intel Core Ultra 5 250K Plus 18 Core up to 5.30 GHz FCLGA1851 Processor
If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, within 24 hours on weekdays.
-
Shipping Information
Use this text to answer questions in as much detail as possible for your customers.
-
Customer Support
Use this text to answer questions in as much detail as possible for your customers.
-
FAQ’s
Use this text to answer questions in as much detail as possible for your customers.
-
Contact Us
Use this text to answer questions in as much detail as possible for your customers.
Explore the Intel Core Ultra 5 250K Plus 18 Core up to 5.30 GHz FCLGA1851 Processor. This processor features an 18-core design, operates with a maximum frequency of 5.30 GHz, and is compatible with the FCLGA1851 socket.
Key Features at a Glance
- Intel Core Ultra 5 250K Plus series
- Equipped with an 18-core architecture
- Capable of speeds up to 5.30 GHz
- Utilizes the FCLGA1851 socket type
Advanced Core Design
The Intel Core Ultra 5 250K Plus processor incorporates an 18-core structure, defining its fundamental processing capability.
High Operating Frequency
This processor is specified to operate at a maximum frequency of 5.30 GHz, providing its clock speed characteristic.
FCLGA1851 Socket Compatibility
The Intel Core Ultra 5 250K Plus is designed for integration with motherboards supporting the FCLGA1851 socket type.
Technical Specifications
| Essentials | |
| Product Collection | Intel Core Ultra Processors (Series 2) |
| Code Name | Products formerly Arrow Lake |
| Vertical Segment | Desktop |
| Processor Number | 250K PLUS |
| CPU Specifications | |
| Total Cores | 18 |
| # of Performance-cores | 6 |
| # of Efficient-cores | 12 |
| # of Low Power Efficient-cores | 0 |
| Total Threads | 18 |
| Max Turbo Frequency | 5.3 GHz |
| Performance-core Max Turbo Frequency | 5.3 GHz |
| Efficient-core Max Turbo Frequency | 4.6 GHz |
| Performance-core Base Frequency | 4.2 GHz |
| Efficient-core Base Frequency | 3.3 GHz |
| Cache | 30 MB Intel Smart Cache |
| Total L2 Cache | 30 MB |
| Processor Base Power | 125 W |
| Maximum Turbo Power | 159 W |
| Intel Deep Learning Boost (Intel DL Boost) on CPU | Yes |
| AI Software Frameworks Supported by CPU | OpenVINO | WindowsML | DirectML | ONNX RT | WebNN |
| CPU Lithography | TSMC N3B |
| Memory Specifications | |
| Max Memory Size (dependent on memory type) | 256 GB |
| Memory Types | Up To DDR5 7200 MT/s |
| Max # of Memory Channels | 2 |
| ECC Memory Supported | Yes |
| GPU Specifications | |
| GPU Name | Intel Graphics |
| Graphics Base Frequency | 300 MHz |
| Graphics Max Dynamic Frequency | 1.9 GHz |
| GPU Peak TOPS (Int8) | 8 |
| Graphics Output | eDP1.4b | DP 2.1 UHBR20 | HDMI 2.1 FRL |
| Xe-cores | 4 |
| Max Resolution (HDMI) | 4096 x 2304 @ 60Hz (HDMI 2.1 TMDS)7680 x 4320 @ 60Hz (HDMI 2.1 FRL) |
| Max Resolution (DP) | 7680 x 4320 @ 60Hz |
| Max Resolution (eDP - Integrated Flat Panel) | 3840 x 2400 @ 120Hz |
| DirectX* Support | 12 |
| OpenGL* Support | 4.5 |
| OpenCL* Support | 3 |
| H.264 Hardware Encode/Decode | Yes |
| H.265 (HEVC) Hardware Encode/Decode | Yes |
| AV1 Encode/Decode | Yes |
| Intel Quick Sync Video | Yes |
| # of Displays Supported | 4 |
| Device ID | 0x7D67 |
| Intel Deep Learning Boost (Intel DL Boost) on GPU | Yes |
| AI Software Frameworks Supported by GPU | OpenVINO | WindowsML | DirectML | ONNX RT | WebGPU |
| NPU Specifications | |
| NPU Name | Intel® AI Boost |
| NPU Peak TOPS (Int8) | 13 |
| Sparsity Support | Yes |
| Windows Studio Effects Support | Yes |
| AI Software Frameworks Supported by NPU | OpenVINO | WindowsML | DirectML | ONNX RT | WebNN |
| Expansion Options | |
| Direct Media Interface (DMI) Revision | 4 |
| Max # of DMI Lanes | 8 |
| Intel Thunderbolt 4 | Yes |
| Scalability | 1S Only |
| PCI Express Revision | 5.0 and 4.0 |
| PCI Express Configurations | Up to 1x16+2x4 | 2x8+2x4 | 1x8+4x4 |
| Max # of PCI Express Lanes | 24 |
| Package Specifications | |
| Sockets Supported | FCLGA1851 |
| Thermal Solution Specification | PCG 2020A |
| Max Operating Temperature | 105 °C |
| Package Size | 45 mm x 37.5 mm |
| Advanced Technologies | |
| Intel Gaussian & Neural Accelerator | 3.5 |
| Intel Thread Director | Yes |
| Intel Speed Shift Technology | Yes |
| Intel Turbo Boost Technology | 2 |
| Intel Hyper-Threading Technology | No |
| Intel 64 | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel SSE4.1 | Intel SSE4.2 | Intel AVX2 |
| Idle States | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Security & Reliability | |
| Intel vPro Eligibility | Intel vPr Enterprise |
Frequently Asked Questions
Q: What model series is this processor from?
A: This is an Intel Core Ultra 5 250K Plus series processor.
Q: How many cores does this processor feature?
A: The Intel Core Ultra 5 250K Plus processor has an 18-core design.
Q: Which socket type is required for this processor?
A: This processor is compatible with the FCLGA1851 socket type.
