Elevate your computing experience with the INTEL CORE I9-12900KS 12TH GEN 16 CORE UPTO 2.50 GHZ LGA1700 PROCESSOR. Designed for demanding tasks, this 12th Gen processor features 16 cores, an LGA1700 socket, and advanced cache memory, delivering robust performance and impressive visuals for your system.
Key Features at a Glance
- Features 16 cores and an LGA1700 socket.
- Equipped with 4 MB L2 + 30 MB L3 cache memory for rapid data access.
- Includes a built-in Intel UHD Graphics 770 controller.
- Engineered to enable improved overall system performance.
- Designed to provide great graphics and visual quality.
Enhanced System Performance
The INTEL CORE I9-12900KS processor integrates 4 MB L2 and 30 MB L3 cache memory, designed to deliver an excellent hit rate in short access time. This sophisticated cache architecture works to enable significantly improved overall system performance, making your computing tasks smoother and more efficient.
Integrated Visuals for Quality Display
Experience vibrant visuals directly from your processor with the built-in Intel UHD Graphics 770 controller. This integrated graphics solution is designed to provide great graphics and visual quality, perfect for everyday computing and enjoying media content without the need for a separate graphics card.
Technical Specifications
| Essentials | |
| Product Collection | 12th Generation Intel® Core™ i9 Processors |
| Code Name | Products formerly Alder Lake |
| Vertical Segment | Desktop |
| Processor Number | i9-12900KS |
| Lithography | Intel 7 |
| Use Conditions | PC/Client/Tablet |
| CPU Specifications | |
| Total Cores | 16 |
| # of Performance-cores | 8 |
| # of Efficient-cores | 8 |
| Total Threads | 24 |
| Max Turbo Frequency | 5.50 GHz |
| Intel® Thermal Velocity Boost Frequency | 5.50 GHz |
| Intel® Turbo Boost Max Technology 3.0 Frequency | 5.30 GHz |
| Efficient-core Max Turbo Frequency | 4.00 GHz |
| Performance-core Base Frequency | 3.40 GHz |
| Efficient-core Base Frequency | 2.50 GHz |
| Performance-core Max Turbo Frequency | 5.20 MHz |
| Total L2 Cache | 14 MB |
| Processor Base Power | 150 W |
| Maximum Turbo Power | 241 W |
| Cache | 30 MB Intel® Smart Cache |
| Embedded Options Available | No |
| Memory Specifications | |
| Max Memory Size (dependent on memory type) | 128 GB |
| Memory Types |
Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s |
| Max # of Memory Channels | 2 |
| Max Memory Bandwidth | 76.8 GB/s |
| ECC Memory Supported | Yes |
| Processor Graphics | |
| Processor Graphics | Intel® UHD Graphics 770 |
| Graphics Base Frequency | 300 MHz |
| Graphics Max Dynamic Frequency | 1.55 GHz |
| Graphics Output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
| Execution Units | 32 |
| Max Resolution (HDMI) | 4096 x 2160 @ 60Hz |
| Max Resolution (DP) | 7680 x 4320 @ 60Hz |
| Max Resolution (eDP - Integrated Flat Panel) | 5120 x 3200 @ 120Hz |
| DirectX* Support | 12 |
| OpenGL* Support | 4.5 |
| Multi-Format Codec Engines | 2 |
| Intel® Quick Sync Video | Yes |
| Intel® Clear Video HD Technology | Yes |
| # of Displays Supported | 4 |
| Device ID | 0x4680 |
| OpenCL* Support | 3.0 |
| Expansion Options | |
| Direct Media Interface (DMI) Revision | 4.0 |
| Max # of DMI Lanes | 8 |
| Scalability | 1S Only |
| PCI Express Revision | 5.0 and 4.0 |
| PCI Express Configurations | Up to 1x16+4, 2x8+4 |
| Max # of PCI Express Lanes | 20 |
| Package Specifications | |
| Sockets Supported | FCLGA1700 |
| Max CPU Configuration | 1 |
| Thermal Solution Specification | PCG 2022E |
| Intel® Thermal Velocity Boost Temperature | 50 °C |
| TJUNCTION | 90°C |
| Package Size | 45.0 mm x 37.5 mm |
| Advanced Technologies | |
| Intel® Gaussian & Neural Accelerator | 3.0 |
| Intel® Thread Director | Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) | Yes |
| Intel® Optane™ Memory Supported | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® Adaptive Boost Technology | Yes |
| Intel® Thermal Velocity Boost | Yes |
| Intel® Turbo Boost Max Technology 3.0 | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Hyper-Threading Technology | Yes |
| Intel® 64 | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
| Idle States | Yes |
| Enhanced Intel SpeedStep® Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Security & Reliability | |
| Intel vPro® Platform Eligibility | Intel vPro® Enterprise |
| Intel vPro® Enterprise Platform Eligibility | Yes |
| Intel® Threat Detection Technology (TDT) | Yes |
| Intel® Active Management Technology (AMT) | Yes |
| Intel® Standard Manageability (ISM) | Yes |
| Intel® Standard Manageability (ISM) | Yes |
| Intel® Hardware Shield Eligibility | Yes |
| ntel® AES New Instructions | Yes |
| Secure Key | Yes |
| Intel® OS Guard | Yes |
| Intel® Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| Intel® Boot Guard | Yes |
| Mode-based Execute Control (MBEC) | Yes |
| Intel® Control-Flow Enforcement Technology | Yes |
| Intel® Total Memory Encryption - Multi Key | Yes |
| Intel® Total Memory Encryption | Yes |
| Intel® Virtualization Technology with Redirect Protection (VT-rp) ‡ | Yes |
| Intel® Virtualization Technology (VT-x) ‡ | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | Yes |
| Intel® VT-x with Extended Page Tables (EPT) ‡ | Yes |
| Warranty | 3 Years |
Frequently Asked Questions
Q: What is the cache memory configuration of this processor?
A: The INTEL CORE I9-12900KS features a total of 4 MB L2 and 30 MB L3 cache memory, totaling 34 MB.
Q: Does this processor include integrated graphics?
A: Yes, it comes with a built-in Intel UHD Graphics 770 controller, providing integrated visual capabilities.
Q: How does the cache memory benefit system performance?
A: The cache memory provides an excellent hit rate in short access time, which significantly contributes to improved overall system performance.
