Specifications



Category Specification
GPU Engine Specs
Graphics Processing GeForce RTX™ 5070
Architecture Blackwell
CUDA Cores 6144
Base Clock 2325 MHz
Boost Clock 2542 MHz
NVIDIA GPU Boost™ Yes
Memory Specs
Memory Size 12 GB
Memory Type GDDR7
Memory Clock 28 Gbps
Memory Interface Width 192-bit
Memory Bandwidth 672 GB/sec
Power & Thermal
Minimum System Power 650W
Power Connectors 2x PCIe 8-pin (adapter in box) OR 300W+ PCIe Gen 5 cable
Bus & Interface
Bus Standard PCI Express Gen 5
PCB Form Factor ATX
Display & Output
Standard Display Outputs 3x DisplayPort 2.1b, 1x HDMI 2.1b
Maximum Digital Resolution 4K @ 480Hz or 8K @ 165Hz (with DSC)
Multi-Monitor Support Up to 4
HDCP 2.3
Feature Support
DirectX 12 Ultimate
OpenGL 4.6
Vulkan API 1.4
Real-Time Ray Tracing Yes (4th Gen RT Cores, 94 TFLOPS)
Tensor Cores 5th Gen, 988 AI TOPS
DLSS Version 4
NVIDIA Ansel Yes
NVIDIA FreeStyle Yes
NVIDIA ShadowPlay Yes
NVIDIA Highlights Yes
G-SYNC™ Ready Yes
Game Ready Drivers Yes
Studio Drivers Yes
NVIDIA Encoder 1x Ninth Generation
NVIDIA Decoder 1x Sixth Generation
OS Compatibility Windows 11 / 10, Linux, FreeBSDx86
Physical Specs
Card Dimensions (L×H×W) 300 × 116 × 41 mm
Accessories 1x Quick Guide 1x 12V-2x6 to 2x PCIe 8-pin Adapter
Warranty 3 Years
