The HYTE Y40 ATX Mid Tower Cabinet in black and white offers a visually striking and high-performance foundation for your PC build. Featuring a multi-dimensional design with panoramic glass, extensive vertical GPU support, and advanced cooling capabilities, this cabinet ensures both stunning aesthetics and optimal functionality for your components.
Key Features at a Glance
- Multi-dimensional design with panoramic glass for an unobstructed view.
- Supports 4-slot vertical graphics cards with enhanced airflow.
- Includes a luxury PCIe 4.0 riser cable for seamless integration.
- Pre-installed with two 120mm fans for immediate cooling.
- Accommodates up to a 280mm radiator on the side and a 360mm radiator on top.
- Compatibility with large air coolers over 180mm in height.
Stunning Panoramic Design
Experience a deeply harmonic design structure where every detail connects with tightly controlled beveling for a premium aesthetic. The 2-Piece Panoramic Glass provides a completely unobstructed view, showcasing your system’s performance and components in their full glory.
Enhanced Vertical GPU Display and Cooling
The Y40 expands GPU support to 4 full slots, allowing for additional airflow space between the graphics card and the glass panel. An intake fan positioned below the power supply shroud directs fresh air upwards, significantly improving cooling performance for your GPU.
Seamless PCIe 4.0 Integration
Enjoy convenient and secure installation with an included luxury PCIe 4.0 riser cable. Its protective canopy integrates beautifully into the case, also providing space for half-height PCIe cards behind your vertical graphics card.
Advanced Cooling Capabilities
Equipped with two pre-installed 120mm fans, one beneath the floor and one at the rear, the Y40 offers immediate cooling. Its side mount supports radiators up to 280mm with a combined thickness of 120mm, ideal for custom loop configurations, while the top mount fits radiators up to 360mm for dual setups. The cabinet also supports large air coolers exceeding 180mm in height, ensuring compatibility with most CPU cooling solutions.
Technical Specifications
|
Type
|
ATX Mid Tower |
|
Volume
|
50L |
|
Case Dimensions
|
439mm x 240mm x 472mm? |
|
Motherboard Support?
|
ITX, mATX, ATX? |
|
Power Supply
|
ATX up to 224mm in length? |
|
Video Card Max Dimensions?
|
422mm length, 94mm height (80mm height or less recommended for best cooling)? |
|
Fan Support? (Side)
|
2x 120mm/140mm? |
|
Fan Support (Top)
|
Top: 3x 120mm? |
|
Fan Support (Rear)
|
1x 120mm (1x 120mm, 1300 rpm included)? |
|
Fan Support (Bottom)
|
1x 120mm/140mm (1x 120mm, 1300 rpm included)? |
|
Radiator Support? (Side)
|
120, 140, 240, 280mm up to 120mm thick? |
|
Radiator Support? (Top)
|
120, 240, 360mm? |
|
Radiator Support? (Rear)
|
120mm? |
|
CPU Cooler Height?
|
183mm |
|
Storage
|
1 x 3.5" HDD or 2 x 2.5" SSD? |
|
Expansion Slots?
|
4 + 6 half-height? |
|
Sku
|
CS-HYTE-Y40-BW, CS-HYTE-Y40-B, CS-HYTE-Y40-BR, CS-HYTE-Y40-WW |
Frequently Asked Questions
Q: What kind of GPU support does the HYTE Y40 offer?
A: The HYTE Y40 supports 4 full-slot vertical graphics cards, designed with additional airflow space for optimal cooling.
Q: How many fans are pre-installed in the HYTE Y40 cabinet?
A: Two 120mm fans come pre-installed: one located beneath the floor and another at the rear of the cabinet.
Q: What are the radiator support options for the HYTE Y40?
A: The side mount can accommodate up to a 280mm radiator with a combined thickness of 120mm, and the top mount supports up to a 360mm radiator.
