Specifications



Specification Details
Product Number MFL-B2DN-183PA-R1
Series MasterFan
Cooler Type Case Fan
Fan Size 120 mm
Dimensions (L x W x H) 120 x 120 x 25 mm / 4.7 x 4.7 x 1.0 inch
Fan Bearing Type Rifle Bearing
Fan MTTF 160,000 Hours
Fan Rated Voltage 12 VDC
Fan Rated Current 0.25A
Fan Safety Current 0.37A
Fan Power Consumption 3.0W
Fan Power Connector 4-Pin (PWM)
Fan Speed 650–1800 RPM ± 10%
Fan Airflow 47.2 CFM ± 10%
Fan Air Pressure 1.6 mmH₂O ± 10%
Fan Noise Level 6 – 30 dBA
Fan Weight 180g x 3
RGB Rated Voltage 5 VDC
RGB Rated Current 0.55A
RGB Connector 3-Pin
LED Lighting ARGB
Number of LEDs 24 pcs x 3
Fan Profiles Addressable Gen 2 RGB
Note Products manufactured after 1st June 2021 are Addressable Gen 2 RGB LEDs
Warranty 2 years
