The DLINK 28-PORT 10-GIGABIT SMART MANAGED POE SWITCH DGS-1250-28XMP offers advanced networking capabilities for modern IT infrastructures. This smart managed switch provides a comprehensive solution with high-speed connectivity and robust power delivery, designed to meet demanding network requirements.
Key Features at a Glance
- 24 x 10/100/1000BASE-T PoE ports
- 4 x 10G SFP+ ports
- 370W PoE Power Budget (802.3af/at)
- Lite L3 Static Routing
- Advanced security features
- Dual Image & Configuration
High-Speed Connectivity and Power-over-Ethernet
This smart managed switch combines 24 Gigabit Ethernet PoE ports with 4 10G SFP+ uplink ports, allowing flexible network expansion and high-bandwidth connections. A substantial 370W PoE power budget (802.3af/at) efficiently supports numerous powered devices.
Enhanced Network Efficiency and Security
Benefit from improved data flow and network security. The switch features Lite L3 Static Routing for increased network efficiency and advanced security options such as Access Control List, IMPB, and 802.1X Authentication to protect your IT network infrastructure.
Reliable Performance and Flexible Management
Ensure consistent network uptime with Dual Image & Configuration for reduced downtime risks. It supports STP/RSTP/MSTP to maintain network quality and offers Full CLI along with 11 Web Languages for diverse management preferences and flexibility.
Technical Specifications
|
CPU Speed
|
800MHz |
|---|---|
|
Dimensions
|
440mm x 250mm x 44mm |
|
DRAM Size
|
DDR3 2G |
|
FAN
|
Smart Fan |
|
Flash Memory Size
|
64MB |
|
Humidity
|
Operating: 0% - 95% RH Storage: 0% - 95% RH |
|
Interfaces
|
24 x 10/100/1000BASE-T ports 4 x 10G SFP+ ports |
|
Max. Packet Forwarding Rate
|
95.24 Mpps |
|
Maximum Heat Dissipation
|
PoE Off: 131.626 BTU/hr (100 V) 133.331 BTU/hr (240 V) PoE ON: 1551.891 BTU/hr (100 V) 1471.415 BTU/hr (240 V) |
|
Maximum Power Consumption
|
PoE Off: 38.6 W/100 V 39.1 W/240 V PoE ON: 455.1 W/100 V 431.5 W/240 V |
|
MTBF
|
463,430.16 hours |
|
Operating Altitude
|
1500 m |
|
Packet Buffer Size
|
12 Mbits |
|
PoE Power Budget
|
370 W |
|
Power Input
|
100 to 240 V AC |
|
Switch Capacity
|
128 Gbps |
|
Temperature
|
Operating: -5 to 50° C (23 to 122° F) Storage -20 - 70°C |
|
Weight
|
3.46 kg |
Frequently Asked Questions
Q: How many PoE ports does this switch have?
A: The DLINK 28-PORT 10-GIGABIT SMART MANAGED POE SWITCH DGS-1250-28XMP features 24 x 10/100/1000BASE-T PoE ports.
Q: What is the PoE power budget for this device?
A: It has a 370W PoE Power Budget, supporting 802.3af/at standards for connected devices.
Q: Does this switch offer advanced security features?
A: Yes, it includes advanced security features such as Access Control List, IMPB, and 802.1X Authentication to protect your network.
