Experience reliable power delivery with the DEEPCOOL PL750D 750 WATT 80 PLUS BRONZE ATX 3.1 SMPS. This robust power supply unit is designed to meet the demands of modern computing systems, offering efficient and stable performance for your setup.
Key Features at a Glance
- 750 WATT power output for demanding systems
- 80 PLUS BRONZE efficiency rating for reduced energy consumption
- Compliance with the ATX 3.1 standard
- Reliable SMPS (Switched-Mode Power Supply) design
Efficient Power Delivery
The 750 WATT output combined with an 80 PLUS BRONZE efficiency rating ensures your system receives stable and cost-effective power, helping to reduce energy waste during operation.
Modern ATX 3.1 Standard
Built to the ATX 3.1 standard, this SMPS is prepared to support current and future component requirements, offering compatibility and readiness for advanced setups.
Technical Specifications
| Category | Details |
|---|---|
| Type | ATX12V V3.1 |
| Product Dimensions | 150 × 140 × 86 mm (W x L x H) |
| Efficiency Certification | 80Plus Bronze |
| Fan Size | 120 mm |
| Fan Bearing | HYB (Hydro Bearing) |
| Topology | Active PFC + DC to DC |
| Capacitors | Chinese Electrolytic Capacitors |
| Power Good Signal | 100-150 ms |
| Hold Up Time | ≥ 16 ms |
| Efficiency | ≥ 85% Under Typical Load (50% Loading) |
| Protection | OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO |
| Operation Temperature | 0 - 40 ℃ |
| Regulatory | CE/FCC/CCC/RCM/EAC/BIS/CAN ICES-003(B)/NMB-003(B)/TUV-RH |
| ErP Regulation | ErP 2014 |
| Environment Protection | WEEE/中国 RoHS/Triman/P65 |
| MTBF | 100,000 Hours |
| EAN P/N |
|
Frequently Asked Questions
Q: What is the power output of this SMPS?
A: The DEEPCOOL PL750D provides a total power output of 750 WATTs.
Q: What efficiency rating does this power supply have?
A: It boasts an 80 PLUS BRONZE efficiency rating, indicating optimized power usage.
Q: Which ATX standard does the DEEPCOOL PL750D support?
A: This power supply unit complies with the ATX 3.1 standard.
