Introducing the DEEPCOOL GAMER STORM PSU PN650D GOLD ATX 3.1 SMPS. This power supply unit (PSU) is part of the DEEPCOOL GAMER STORM series.
Key Features at a Glance
- DEEPCOOL GAMER STORM brand
- PN650D model identifier
- GOLD efficiency rating
- ATX 3.1 standard
- SMPS technology
Understanding the GOLD Rating
The DEEPCOOL GAMER STORM PSU PN650D is noted for its GOLD rating, a standard designation within power supply units.
Exploring ATX 3.1 Standards
This PSU adheres to the ATX 3.1 specification, an industry benchmark for power supply design and functionality.
PN650D: A Core Model
The PN650D identifier marks this specific model within the DEEPCOOL GAMER STORM series, distinguishing its core attributes as an SMPS.
Technical Specifications
| Type | ATX12V V3.1 |
| Product Dimensions | 150×140×86mm (W x L x H) |
| Efficiency certification | 80Plus Gold |
| Fan Size | 120mm |
| Fan Bearing | HYB(Hydro Bearing) |
| Topology | Active PFC + Full Bridge SRC LLC + DC to DC |
| Capacitors | Chinese Electrolytic Capacitors |
| Power Good Signal | 100-150ms |
| Hold Up Time | ≥16ms(80% Load) |
| Efficiency | ≥90% Under Typical Load(50% Loading) |
| Protection | OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO |
| Operation Temperature | 0 - 40℃ |
| Regulatory | CE/FCC/CCC/TUV-RH/cTUVus/RCM/EAC |
| Erp Regulation | ErP 2014 |
| Environment Protection | WEEE/中国 RoHS/Triman/P65 |
| MTBF | 100,000 Hours |
Frequently Asked Questions
Q: What type of product is this?
A: This is a DEEPCOOL GAMER STORM PSU, which stands for Power Supply Unit.
Q: What is the efficiency rating for this unit?
A: The DEEPCOOL GAMER STORM PSU PN650D has a GOLD efficiency rating.
Q: Which ATX standard does this power supply support?
A: This power supply unit (PSU) supports the ATX 3.1 standard.
