Elevate your system's performance with the DEEPCOOL GAMER STORM PSU PN1200M ATX 3.1 FULLY MODULAR GOLD. This high-performance power supply unit is engineered to meet the demands of modern computing, offering stable power delivery, exceptional efficiency, and a fully modular design for a clean and optimized build.
Key Features at a Glance
- ATX 3.1 standard compliance
- Fully modular cable management
- 80 PLUS Gold certified efficiency
- High-performance GAMER STORM PSU
Next-Generation ATX 3.1 Support
Designed with the latest ATX 3.1 standard, this power supply ensures robust compatibility and stable power delivery for current and future high-performance components, providing peace of mind for your system's needs.
Streamlined Cable Management
Benefit from a fully modular design, allowing you to connect only the cables you need. This leads to a cleaner internal aesthetic, improved airflow within your PC case, and a more straightforward build process.
Optimized Power Efficiency
The 80 PLUS Gold certification signifies superior power efficiency. This translates to less wasted energy as heat, lower operating temperatures for your components, and a more energy-efficient system overall.
Technical Specifications
| Type | ATX12V V3.1 |
| Product Dimensions | 150×150×86mm (W x L x H) |
| Efficiency certification | 80Plus Gold |
| Fan Size | 135mm |
| Fan Bearing | FDB (Fluid Dynamic Bearing) |
| Topology | Active PFC + Half Bridge SRC LLC + DC to DC |
| Capacitors | Japanese Bulk Capacitor |
| Power Good Signal | 100-150ms |
| Hold Up Time | ≥16ms(80% Load) |
| Efficiency | ≥90% Under Typical Load(50% Loading) |
| Protection | OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO |
| Operation Temperature | 0 - 40℃ |
| Regulatory | CE/FCC/CCC/TUV-RH/cTUVus/RCM/EAC/BIS |
| Erp Regulation | ErP 2014 |
| Environment Protection | WEEE/中国 RoHS/Triman/P65 |
| MTBF | 100,000 Hours |
Frequently Asked Questions
Q: What are the key features of the DEEPCOOL GAMER STORM PN1200M?
A: This power supply unit features ATX 3.1 standard compliance, a fully modular design, and 80 PLUS Gold certified efficiency under the DEEPCOOL GAMER STORM series.
Q: What does "Fully Modular" mean for this power supply?
A: A fully modular design allows users to detach all power cables not in use, simplifying installation, reducing cable clutter, and improving airflow within the PC case.
Q: What does the "Gold" rating indicate for this PSU?
A: The "Gold" rating refers to its 80 PLUS Gold certification, which guarantees a high level of power efficiency, meaning less energy is wasted as heat during operation.
