The DEEPCOOL ASSASSIN IV VC VISION AIR COOLER is an air cooling unit from DEEPCOOL, identified by the model R-ASN4-BKNVMD-G. This cooler incorporates the VISION element within its design, providing a functional component for your system.
Key Features at a Glance
- Product from the DEEPCOOL brand
- Model: ASSASSIN IV VC VISION
- Functions as an air cooler
- Includes VISION design element
Core Cooling Functionality
The DEEPCOOL ASSASSIN IV VC VISION AIR COOLER is fundamentally an air cooling component. Its primary purpose is to contribute to the thermal management of a system.
VISION Design Element
The inclusion of "VISION" in the product name signifies a particular design element or characteristic integrated into this model.
Technical Specifications
| Bearing Type | Fluid Dynamic Bearing |
|---|---|
| Display Area | 44.6x53.6 mm |
| Display Module Power Consumption | 0.4 W |
| Display Module Rated Current | 0.08 A±10% |
| Display Module Rated Voltage | 5 VDC |
| Fan Air Pressure (Performance Mode) | 3.76 mmAq / 2.1 mmAq |
| Fan Air Pressure (Quiet Mode) | 2.46 mmAq / 1.35 mmAq |
| Fan Airflow (Performance Mode) | 61.25 CFM / 58.06 CFM |
| Fan Airflow (Quiet Mode) | 48.55 CFM / 46.75 CFM |
| Fan Connector | 4-pin PWM |
| Fan Dimensions | 140×140×25 mm(L×W×H) / 120×120×25 mm(L×W×H) |
| Fan Power Consumption | 2.4W / 2.4 W |
| Fan Rated Current | 0.2 A / 0.2 A |
| Fan Rated Voltage | 12 VDC |
| Fan Speed (Performance Mode) | 500~1800 RPM±10% / 500~1700 RPM±10% |
| Fan Speed (Quiet Mode) | 500~1450 RPM±10% / 500~1350 RPM±10% |
| Heatpipe | Ø6 mm×7 pcs |
| Heatsink Dimensions | 140×110×160 mm(L×W×H) |
| Net Weight | 1780 g |
| Overall Noise (Performance Mode) | ≤29.3 dB(A) |
| Overall Noise (Quiet Mode) | ≤22.6 dB(A) |
| P/N | R-ASN4-BKNVMD-G |
| Power Consumption(Performance Mode) | 4.8 W |
| Power Consumption(Quiet Mode) | 3.6 W |
| Product Dimensions | 147×144×172 mm(L×W×H) |
| Rated Voltage | 12 VDC |
Frequently Asked Questions
Q: What is the DEEPCOOL ASSASSIN IV VC VISION AIR COOLER?
A: This is an air cooling unit from the brand DEEPCOOL, identified by the model ASSASSIN IV VC VISION.
Q: What is the primary purpose of this product?
A: The primary purpose of this air cooler is to provide cooling.
Q: What does the "VISION" element in the name signify?
A: The "VISION" element denotes a specific design characteristic or feature integrated into the DEEPCOOL ASSASSIN IV VC VISION AIR COOLER.
