Enhance your PC's power delivery with the COOLER MASTER V1300 80 PLUS PLATINUM V2 ATX 3.1 FULLY MODULAR SMPS. This Cooler Master power supply unit (PSU) features the advanced ATX 3.1 standard and 80 PLUS Platinum efficiency, paired with a fully modular design for optimized system building.
Key Features at a Glance
- COOLER MASTER brand power supply unit.
- V1300 series, indicating 1300W power capacity.
- 80 PLUS PLATINUM efficiency certification.
- Compliant with the ATX 3.1 standard.
- FULLY MODULAR cable management design.
- V2 version identifier.
Exceptional Power Efficiency
The 80 PLUS PLATINUM certification ensures very high power efficiency, converting a significant percentage of input power into usable output power while minimizing energy waste and heat generation within your system.
Advanced ATX 3.1 Compliance
Built to the ATX 3.1 standard, this SMPS is designed to meet the demands of modern computing hardware, providing stable and reliable power delivery for current and future high-performance components.
Streamlined System Assembly
Benefit from a FULLY MODULAR design that allows you to connect only the cables essential for your setup. This reduces internal clutter, improves airflow, and simplifies the installation and upgrade process for your PC.
Reliable Cooler Master Quality
As a Cooler Master product, the V1300 V2 SMPS is engineered for dependability. Its robust construction, designated as V2, provides a stable power foundation for demanding systems.
Technical Specifications
| Model | MPZ-D002-AFAP |
| ATX Version | ATX 12V Ver. 3.1 |
| PFC | Active PFC |
| Input Voltage | 100-240V |
| Input Current | 15-7A |
| Input Frequency | 50-60Hz |
| Dimensions (L x W x H) | 160 x 150 x 86 mm |
| Fan Size | 135mm |
| Fan Bearing | LDB |
| Fan Speed | 2400±10% RPM |
| Efficiency | ? 92% @ Typical Load |
| 80 PLUS Rating | 80 PLUS Platinum |
| ErP 2014 Lot 3 | Yes |
| Operating Temperature | 0-50°C |
| Power Good Signal | 100 - 150 ms |
| Hold Up Time | ? 16ms |
| MTBF | >100,000 Hours |
| Protections | OPP / OVP / OTP / OCP / SCP / UVP / Surge & Inrush Protection |
| Regulatory | cTUVus, TUV, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (Region dependent) |
| ATX 24 Pin Connectors | 1 |
| EPS 4+4 Pin Connectors | 1 |
| EPS 8 Pin Connector | 1 |
| SATA Connectors | 16 |
| Peripheral 4 Pin Connectors | 4 |
| PCI-e 6+2 Pin Connectors | 5 |
| 12V-2x6 Connectors | 1 |
| Series | V Platinum Series |
| 80 Plus Efficiency | Platinum |
| Modular | Fully Modular |
| Category | Above 750W |
| Form Factor | ATX |
| Watts | 1300W |
Frequently Asked Questions
Q: What does the '80 PLUS PLATINUM' rating signify?
A: The '80 PLUS PLATINUM' certification indicates that this power supply operates at a very high level of energy efficiency, reducing electricity consumption and heat output during operation.
Q: Why is 'ATX 3.1' important for a power supply?
A: 'ATX 3.1' is the latest industry standard for power supply design, ensuring compatibility with the newest hardware components and providing optimized power delivery, especially for high-power graphics cards.
Q: What are the advantages of a 'FULLY MODULAR' SMPS?
A: A 'FULLY MODULAR' design allows users to connect only the power cables needed for their system, leading to cleaner cable management, improved internal airflow, and easier installation or upgrades.
