Discover the COOLER MASTER MWE BRONZE 650 V3 ATX 3.1 80 PLUS BRONZE SMPS, a reliable power supply designed to meet your system's energy needs. This 650W unit from Cooler Master combines ATX 3.1 compatibility with 80 PLUS Bronze efficiency, offering a robust foundation for your build.
Key Features at a Glance
- Reliable Cooler Master power supply
- 650W continuous power output
- Supports the ATX 3.1 standard
- 80 PLUS Bronze efficiency certification
- Part of the MWE Bronze V3 series
- Designed as a Switched-Mode Power Supply (SMPS)
Robust Power Output
With a 650W capacity, the COOLER MASTER MWE BRONZE 650 V3 SMPS provides stable and consistent power, ensuring your system components receive the energy they need to operate efficiently. Its ATX 3.1 compatibility prepares your build for modern hardware demands.
Certified Efficiency
The 80 PLUS Bronze certification signifies that this power supply operates with improved efficiency, converting more AC power into usable DC power for your system while generating less waste heat. This contributes to a cooler and potentially quieter computing environment.
Cooler Master Quality
Built by Cooler Master, a trusted name in PC components, the MWE BRONZE 650 V3 carries the brand's commitment to quality. This SMPS is engineered to deliver dependable performance as a core component of your computer setup.
Technical Specifications
|
Product Name |
MWE Bronze 650 V3 230V |
|
Item Code |
MPE-6501-ACABW-3BIN |
|
ATX Version |
ATX 12V Ver. 3.1 |
|
PFC |
Active PFC |
|
Input Voltage |
200 - 240V |
|
Input Current |
5A |
|
Input Frequency |
50 - 60Hz |
|
Dimensions (L x W x H) |
140 x 150 x 86mm |
|
Fan Size |
120 mm |
|
Fan Bearing |
HDB |
|
Efficiency |
≥ 88% @ Typical Load |
|
80 PLUS Rating |
80 PLUS Bronze |
|
ErP 2014 Lot 3 |
Yes |
|
Operating Temperature |
0 ~ 40℃ |
|
Power Good Signal |
100 - 150ms |
|
Hold Up Time |
≥ 16ms |
|
MTBF |
>100,000 hours @ 25℃ ambient |
|
Protections |
UVP / OVP / OPP / OTP / SCP |
|
Regulatory |
TUV, CE, FCC, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (based on region's request.) |
|
Connectors |
ATX 24 Pin: x1 = 1x (500mm) EPS 8Pin / 4+4 Pin: x2 = 1x (550+120mm) SATA: x6 = 2x (400+150+150mm) Peripheral 4 Pin: x3 = 1x (400+150+150mm) PCI-e 6+2 Pin: x4 = 2x (500+120mm) |
|
Weight |
Net: 1.65 kg Gross: 2.05 kg |
|
Package Dimensions |
245 x 190 x 110mm (9.65 x 7.48 x 4.33") |
|
Warranty |
5 years |
Frequently Asked Questions
Q: What is the power output of this SMPS?
A: The COOLER MASTER MWE BRONZE 650 V3 provides 650 watts of power.
Q: What is its efficiency certification?
A: This SMPS is 80 PLUS Bronze certified, indicating its energy efficiency.
Q: Which ATX standard does this power supply support?
A: It supports the ATX 3.1 standard.
