Introducing the COOLER MASTER MWE 850 VSFX 80 PLUS GOLD ATX 3.1 FULLY MODULAR SMPS. This power supply unit offers 80 PLUS Gold efficiency and features a fully modular design, adhering to the ATX 3.1 standard for reliable performance in your system.
Key Features at a Glance
- 80 PLUS Gold certified for high energy efficiency.
- Complies with the ATX 3.1 power supply standard.
- Features a fully modular cable system for streamlined builds.
- Offers 850W power capacity.
- Part of the Cooler Master MWE VSFX series.
Efficient Power Delivery
The 80 PLUS Gold certification ensures high energy efficiency, translating to less wasted heat and potentially lower operating costs for your system while providing stable power.
Streamlined System Builds
A fully modular design allows you to connect only the necessary cables, simplifying installation and improving airflow within your PC case for a cleaner, more organized aesthetic.
Modern Standard Compliance
Built to the ATX 3.1 standard, this power supply unit provides modern compatibility and reliable power delivery, supporting a wide range of current and future components.
Technical Specifications
| Specification | Details |
|---|---|
| Model | MPY-8501-SFHAGV-3EIN |
| ATX Version | SFX 12V Ver. 3.42 |
| PFC | Active PFC |
| Input Voltage | 100-240V |
| Input Current | 12-6A |
| Input Frequency | 50-60Hz |
| Dimensions (L x W x H) | 100 x 125 x 63.5 mm |
| Fan Size | 92mm |
| Fan Bearing | FDB |
| Efficiency | 90% @ Typical Load |
| 80 PLUS Rating | 80 PLUS Gold |
| ETA Rating | Gold |
| LAMBDA Rating | Standard+ |
| ErP 2014 Lot 3 | Yes |
| Operating Temperature | 0-50°C |
| Power Good Signal | 100 - 500 ms |
| Hold Up Time | 16ms |
| MTBF | >100,000 Hours |
| Protections | OPP / OVP / OTP / OCP / SCP / UVP / Surge & Inrush Protection |
| Regulatory | TUV, cTUVus, CE, BSMI, FCC, CCC, EAC, RCM, KCC, CB, UKCA |
| ATX 24 Pin Connectors | 1 |
| EPS 4+4 Pin Connectors | 1 |
| EPS 8 Pin Connector | 1 |
| SATA Connectors | 8 |
| Peripheral 4 Pin Connectors | 4 |
| PCI-e 6+2 Pin Connectors | 4 |
| 80 Plus Efficiency | Gold |
| Series | V SFX Series |
| Modular | Fully Modular |
| Category | Above 750W |
| Form Factor | SFX |
| Watts | 850W |
Frequently Asked Questions
Q: What does "80 PLUS GOLD" certification mean?
A: 80 PLUS Gold certification indicates that a power supply unit operates with high energy efficiency, typically achieving at least 87% efficiency at 20% load, 90% at 50% load, and 87% at 100% load.
Q: What is the benefit of a "Fully Modular" power supply?
A: A fully modular power supply allows all cables to be detached from the unit, enabling users to connect only the cables needed for their system, which significantly improves cable management and airflow within the PC case.
Q: What is the ATX 3.1 standard?
A: ATX 3.1 is the latest power supply design guide from Intel, ensuring compatibility with modern, high-power components like the latest GPUs and CPUs, and providing enhanced stability for system operation.
