The COOLER MASTER MWE 1250 GOLD V2 ATX 3.1 FULLY MODULAR POWER SUPPLY delivers reliable power for your system. Designed for performance and efficiency, this unit provides a robust solution for demanding builds with its fully modular design and adherence to the latest ATX 3.1 standard.
Key Features at a Glance
- 1250W power output
- ATX 3.1 compliance
- Fully modular cable management
- 80 PLUS Gold V2 certified efficiency
- Part of the COOLER MASTER MWE Gold V2 series
Ample Power for Demanding Systems
With a robust 1250W capacity, this power supply is engineered to support high-performance components, including advanced graphics cards and processors, ensuring stable operation for your system.
ATX 3.1 Standard Readiness
Built to the ATX 3.1 standard, this power supply is ready for the latest hardware, providing optimal power delivery and compatibility for modern PC builds.
Fully Modular for Clean Builds
The fully modular design allows you to connect only the necessary cables, reducing clutter within your PC case and improving airflow for a cleaner, more efficient build.
Enhanced Efficiency
Achieve greater energy efficiency with the 80 PLUS Gold V2 certification, meaning less wasted heat and lower operating costs while maintaining reliable power delivery to your components.
Technical Specifications
| Specification | Details |
|---|---|
| Model | MPE-C501-AFCAG-3EIN |
| ATX Version | ATX Rev. 3.1 |
| PFC | Active PFC |
| Input Voltage | 100-240V |
| Input Current | 15-7A |
| Input Frequency | 50-60Hz |
| Dimensions (L x W x H) | 180 x 150 x 86 mm |
| Fan Size | 140mm |
| Fan Bearing | Two Ball Bearing |
| Efficiency | ?90% @ Typical Load |
| 80 PLUS Rating | 80 PLUS Gold |
| ErP 2014 Lot 3 | Yes |
| Operating Temperature | 0-50°C |
| Power Good Signal | 100 - 150 ms |
| Hold Up Time | ?16ms at 100% Load |
| MTBF | >100,000 Hours |
| Protections | OVP / OPP / SCP / OCP / UVP / OTP / Inrush Protection |
| Regulatory | TUV, cTUVus, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, BIS |
| ATX 24 Pin Connectors | 1 |
| EPS 4+4 Pin Connectors | 1 |
| EPS 8 Pin Connector | 1 |
| SATA Connectors | 12 |
| Peripheral 4 Pin Connectors | 4 |
| PCI-e 6+2 Pin Connectors | 3 |
| 12V-2x6 Connectors | 1 |
| Series | MWE Gold Series |
| Category | Above 750W |
| Modular | Fully Modular |
| 80 Plus Efficiency | Gold |
| Form Factor | ATX |
| Watts | 1250W |
Frequently Asked Questions
Q: What is the power output of the COOLER MASTER MWE 1250 GOLD V2?
A: This power supply delivers 1250W of power.
Q: Does this power supply have a modular cable design?
A: Yes, the COOLER MASTER MWE 1250 GOLD V2 is fully modular.
Q: What efficiency certification does it hold?
A: It is 80 PLUS Gold V2 certified.
