The CADYCE CADYCE HDMI EXTENDER OVER ETHERNET WITH IR (50M) CA-HDX50 allows you to effortlessly extend your HDMI audio and video signals over a single Ethernet cable. This reliable extender solution transmits high-definition content and offers convenient infrared (IR) pass-through, making it ideal for various home and professional setups requiring extended reach.
Key Features at a Glance
- Extends HDMI signals using standard Ethernet.
- Supports distances up to 50 meters.
- Features Infrared (IR) pass-through for remote control.
- Designed for reliable high-definition content transmission.
- Model: CA-HDX50.
Extend Your HDMI Reach
Effortlessly transmit your HDMI audio and video from a source device to a display up to 50 meters away. This extender is perfect for scenarios where your source and display are not in close proximity, such as in large rooms, commercial spaces, or home entertainment systems.
Seamless Control with IR
Enjoy full control over your source device from the display location thanks to the integrated IR pass-through functionality. Use your existing remote control to manage Blu-ray players, set-top boxes, or other IR-controlled devices, even when they are in another room.
Reliable Ethernet Connection
Utilizing widely available and cost-effective Ethernet cables, this extender provides a stable and consistent connection for your HDMI signals. Benefit from the robust infrastructure of Ethernet for dependable video and audio delivery.
Technical Specifications
| Specification | Details |
|---|---|
| Features | – Max Resolution – 1080P@60Hz (Full HD) – HDMI Version – HDMI 1.4 – Works with all CAT5/CAT5e/CAT6/ CAT6a/CAT7 types of cables – Maximum Ethernet Cable length Supported – 50m – Gain Adjustment for various lengths (30/40/50m) |
| Max HDMI Resolution Supported | Full HD, 1080p@60Hz |
| HDCP Compliance | HDCP 1.3 |
| Max Cable Length Supported | 50m |
| Product Size (L x W x H) | 81 x 47 x 22mm |
| Product Dimensions | Main – 129 x 45 x 14mm Dual USB-C™ Connector – 45 x 22 x 8mm Cable Length – 165mm |
| Operating Temperature | 0°C to 75°C |
| Operating Humidity | 10% ~ 85% RH (No Condensation) |
| Input Power | 5V DC, 1A |
| Certifications | CE, FCC |
| EAN Code | 0745860907631 |
| Brand | Cadyce |
| LEGAL METROLOGY PRODUCT DECLARATION | KSG TECHNOLOGIES PVT LTD Rahul Commercial Complex S.No.135/136 ‘D’ Wing 3rd Floor Kothrud Paud Road Pune-411029 |
| Details of the items in the package (Number of Units/Quantity) | 1N |
| Country of Origin | China |
| Customer Care | Toll Free No. 18002669910 Support Email ID - RMA@cadyce.com |
| Common/Generic Name of the Product | Computer Networking Accessories (HDMI Extender) |
| Product Reference | CA-HDX50 |
Frequently Asked Questions
Q: What is the maximum distance this HDMI extender can transmit signals?
A: This extender is designed to transmit HDMI signals up to 50 meters.
Q: Does this extender allow me to control my source device from a distance?
A: Yes, it features IR (Infrared) pass-through, which allows you to use your existing remote control for your source device from the display location.
Q: What type of cable is used to connect the sender and receiver units?
A: The extender uses a standard Ethernet cable for signal transmission between the sender and receiver units.
