Asus ROG Thor 1200W Platinum III ATX 3.1 Fully Modular SMPS

The Asus ROG Thor 1200W Platinum III ATX 3.1 Fully Modular SMPS delivers unmatched performance and rock-solid stability for your ultimate PC build. Featuring GaN MOSFETs for superior efficiency, a "GPU-First" patented intelligent voltage stabilizer, and a magnetic OLED display, this power supply unit ensures top-tier power delivery and advanced monitoring for demanding systems.

Key Features at a Glance

• GaN MOSFETs deliver up to 30% more power efficiency and cooler operation.
• "GPU-First" voltage sensing enhances graphics card stability by up to 45%.
• Magnetic OLED display shows real-time power draw and is easily repositionable.
• ATX 3.1 compatible, ensuring enhanced voltage and current regulation for modern hardware.
• ROG heatsinks & aluminum enclosure provide superior cooling, with 0dB Technology for silent operation.
• 80 PLUS & Cybenetics Platinum and Lambda A++ certified for industry-leading efficiency and low noise.

Advanced Efficiency & Optimized Power Delivery

The Asus ROG Thor 1200W Platinum III features innovative GaN MOSFETs for up to 30% more power efficiency compared to standard MOSFETs, ensuring cooler operation. It is 80 PLUS & Cybenetics Platinum certified for industry-leading power efficiency. The unique "GPU-First" voltage sensing with a patented intelligent voltage stabilizer enhances voltage delivery to your graphics card by up to 45%, providing smoother gaming and stable performance.

Intuitive Monitoring & Flexible Control

Monitor real-time power draw with the Magnetic OLED Display, which can be swapped to either side for flexible PSU installation. Activate Turbo Mode for extended power excursions, supported by a fine-tuned fan curve. Integrated Aura Sync addressable RGB LEDs allow for custom lighting effects and Smart Mode, which changes color based on GPU temperature.

Superior Cooling & Long-Term Durability

Designed for longevity, this PSU incorporates ROG heatsinks and a fully aluminum enclosure for superior cooling. Dual-ball-fan bearings offer a lifespan up to twice as long as sleeve-bearing designs, contributing to a lifespan of up to 80,000 hours. The 0dB Technology ensures silent operation when the PSU load is 30% or below. It also features Lambda A++ Certification for low noise levels, below 15 dB. The product is backed by a 10-year warranty.

Effortless Installation & Enhanced Safety

Etched modular cables are made from a pliable premium material, ensuring effortless cable management while operating at significantly lower temperatures than safety limits. These cables meet rigorous UL1581 flame test and UL758 certification standards. A DIY-friendly CPU Power Connector simplifies installation with its distinct clip and unique color scheme.

Technical Specifications

• Cable Connectors:
  • MB 24/20-pin x 1
  • CPU 4+4-pin x 2
  • PCI-E 16-pin x 1
  • PCI-E 6+2-pin x 4
  • SATA x 7
  • PERIPHERAL x 6
• PFC Type: Active PFC
• ATX Standard: ATX 3.1
• MTBF: >120,000 hours @ 25°C
• Protection Features: OPP/OVP/UVP/SCP/OCP/OTP
• Hazardous Materials: ROHS
• AC Input Range: 100-240Vac

Frequently Asked Questions

Q: Does the Asus ROG Thor 1200W Platinum III feature 0dB technology?

A: Yes, the fan shuts off entirely when the PSU load is at 30% or below, providing silent operation during light workloads.

Q: What is the function of the 0dB Fan Button?

A: When the 0dB Fan Button is ON, the fan will only spin up when the system reaches a certain load. When it is OFF, the fan will continuously spin at all load levels.

Q: Can the magnetic OLED display be repositioned?

A: Yes, the detachable magnetic OLED display can be swapped to either side of the unit to accommodate fan-up or fan-down PSU installation, depending on your case design.
