Fan Specifications

• Fan Speed: 400–2650 rpm, PWM controlled 0 rpm below 5 % PWM
• Airflow: 98 cfm | 166.5 m³/h
• Static Pressure: 5.1 mmH2O
• Fan Bearing: Fluid Dynamic Bearing
• Typical Voltage: 12 V DC
• Start Up Voltage: 4 V DC
• Current: 0.4 A
• Cable Length: 400 mm + 80 mm Daisy-Chain Cable
• Connector: 4-Pin Fan Plug + 4-Pin Socket

General Specifications

• Operating Ambient Temperature: 0–40 °C
• Dimensions: 140 (L) x 140 (W) x 30 (H) mm
• Net Weight: 248 g
