Fan Specifications:

  • Fan Speed: 400–2500 rpm, PWM controlled 0 rpm below 5 % PWM
  • Airflow: 110 cfm | 186 m³/h
  • Static Pressure: 5.2 mmH2O
  • Fan Bearing: Fluid Dynamic Bearing
  • Typical Voltage: 12 V DC
  • Start Up Voltage: 5 V DC
  • Current: 0.35 A
  • Cable Length: 400 mm + 80 mm Daisy-Chain Cable
  • Connector: 4-Pin Fan Plug + 4-Pin Socket

General Specifications

  • Operating Ambient Temperature: 0–40 °C
  • Dimensions: 140 (L) x 140 (W) x 27 (H) mm
  • Net Weight: 242 g
