Fan Specifications:

• Fan Speed:  500 -3000 rpm PWM Controlled 0 rpm below 5% PWM
• Airflow: 73 cfm | 124 m³/h
• Static Pressure: 4.5 mmH2O
• Fan Bearing: Fluid Dynamic Bearing
• Typical Voltage: 12 V DC
• Start Up Voltage: 3.5 V DC
• Current: 0.4 A
• Cable Length: 400 mm + 80 mm Daisy-Chain Cable
• Connector: 4-Pin Fan Plug + 4-Pin Socket

RGB Specifications:

• LEDs: 12x A-RGB Gen2 LEDs
• Current | Voltage: 0.40 A | 5 V DC
• Connector: 3-Pin A-RGB Plug + 3-Pin Socket

General Specifications:

• Operating Ambient Temperature: 0–40 °C
• Dimensions: 120 (L) x 120 (W) 27 (H) mm
• Net Weight: 172 g
