Features:

• Operating Ambient Temperature: 0–40 °C
• Dimensions: 120 (L) x 120 (W) x 25 (H)mm

Fan Specifications

• Fan Speed: 600–3000 rpm,PWM controlled 0 rpm below 5 % PWM
• Airflow:  77 cfm|131 m³/h
• Static Pressure:  6.9 mmH2O
• Fan Bearing: Fluid Dynamic Bearing
• Typical Voltage:  12 V DC
• Start Up Voltage: 3.3 V DC
• Current:  0.33 A
• Cable Length:  400 mm + 80 mm Daisy-Chain Cable
• Connector:  4-Pin Fan Plug + 4-Pin Socket

RGB Specifications

• LEDs: 12x A-RGB Gen2 LEDs
• Current | Voltage: 0.40 A | 5 V DC
• Connector: 3-Pin A-RGB Plug + 3-Pin Socket
