Fan Specifications

  • Fan Speed: 600–3000 rpm,PWM controlled 0 rpm below 5 % PWM
  • Airflow:  77 cfm | 131 m³/h
  • Static Pressure: 6.9 mmH2O
  • Fan Bearing:  Fluid Dynamic Bearing
  • Typical Voltage:  12 V DC
  • Start Up Voltage: 3.3 V DC
  • Current: 0.33 A
  • Cable Length: 400 mm
  • Connector:  4-Pin Fan Plug
