The APC EASY UPS ON-LINE SRV6KL-IN is a powerful 6000VA/6000W True On-Line UPS designed to deliver premium, uninterrupted, and pure sine wave power. This system is ideal for critical servers, data centers, and sensitive industrial applications, ensuring reliable protection against power fluctuations and outages with its double-conversion topology.
Key Features at a Glance
- 6000VA/6000W (unity power factor) for maximum load support.
- True double-conversion online topology ensures clean, uninterrupted power.
- Achieves up to 94% efficiency in double-conversion mode and 97% in ECO mode.
- Wide input voltage range of 176-300V (full load) and 110-300V (half load).
- Features USB, RS-232, and an intelligent slot for comprehensive connectivity.
- BIS certified for safety and quality assurance.
Uninterrupted Power Protection
Experience superior power reliability with the true on-line double-conversion topology. This system continuously delivers premium, pure sine wave power, effectively safeguarding critical servers, data centers, and sensitive industrial applications from power disturbances by regenerating a fresh, stable output.
Optimized Energy Efficiency
Designed for efficiency, this UPS operates at up to 94% in double-conversion mode and an impressive 97% in ECO mode. These high efficiency ratings significantly reduce energy consumption and cooling costs, contributing to a more sustainable and cost-effective operation for your business.
Flexible Runtime and Adaptability
The system supports scalable extended runtime through external battery packs (SRV240RBP-9A), providing up to 8 minutes of backup at half load and 2 minutes at full load with one pack. Its wide input voltage range (176-300V full load, 110-300V half load) ensures stable operation even in fluctuating power conditions.
Comprehensive Management and Design
Manage your power solution effectively with a multi-function LCD display for real-time status. Connectivity options include USB and RS-232 ports, plus an intelligent slot for optional network management. Safety features like Emergency Power Off (EPO) and generator compatibility are integrated, all within a rack-mountable 5U form factor.
Technical Specifications
| Category | Details |
|---|---|
| Presentation | High quality, Double-conversion On-line UPS for essential power protection |
| Lead Time | Usually in Stock |
| Product Type | Uninterruptible Power Supply (UPS) |
| Range of Product | Easy UPS On-Line |
| Rated Power (W / VA) | 6000 W / 6000 VA |
| Main Output Voltage | 230 V |
| Other Output Voltage | 220 V, 240 V |
| Main Input Voltage | 230 V |
| Other Input Voltage | 220 V, 240 V |
| Configurable Output Voltage | 220 V, 230 V, 240 V |
| Input Voltage Limits | 110–300 V (60% load), 176–300 V (full load) |
| Input Frequency | 40–70 Hz auto sensing |
| Input Connector Type | 1× Hard wire 3-wire (1P + N + E) |
| Output Connector Type | 1× Hard wire 3-wire (1P + N + E) |
| UPS Type | Double Conversion Online |
| Waveform | Pure Sine Wave |
| Bypass Type | Internal (Automatic and Manual) |
| Crest Factor | 3:1 |
| Output Frequency | 50/60 Hz ±3 Hz (sync to mains) |
| Efficiency (Full Load) | 94% |
| Battery Type | External battery system |
| Battery Voltage | 240 V |
| Extended Runtime Support | No |
| Battery Charger Power | 1170 W rated |
| Battery Slots (Filled / Free) | 0 / 0 |
| Included Equipment | USB cable, RS-232 cable, rack mounting brackets, wall mounting feet, battery cable, user manual |
| Mounting Mode | Rack-mounted with kit |
| Mounting Units | 2U |
| Mounting Location | Front |
| Mounting Position | Horizontal |
| Mounting Preference | Lower |
| Color | Black (RAL 7010) |
| USB Compatible | No |
| Control Panel | Multifunction LCD status and control console |
| Alarm Types | Audible & visible alarms (battery, low battery, overload) |
| Surge Energy Rating | 600 J |
| Acoustic Noise Level | 60 dBA |
| IP Rating | IP20 |
| Operating Temperature | 0–40 °C |
| Storage Temperature | -20–60 °C |
| Operating Altitude | 0–3000 m |
| Storage Altitude | 0–15000 m |
| Relative Humidity (Op/Storage) | 0–95% non-condensing |
| Product Dimensions (H×W×D) | 8.65 × 43.8 × 61.5 cm |
| Product Weight | 15 kg |
| Package Dimensions (H×W×L) | 24 × 76 × 60 cm |
| Package Weight | 18 kg |
| Warranty | 2 Years Repair or Replace |
Frequently Asked Questions
Q: What is the power capacity of the APC EASY UPS ON-LINE SRV6KL-IN?
A: It offers a power capacity of 6000 VA / 6000 W, featuring a unity power factor for maximum load support.
Q: Does this UPS support extended backup runtime?
A: Yes, it is designed for extended runtime, supporting external battery packs (SRV240RBP-9A) to provide up to 8 minutes at half load and 2 minutes at full load with one pack.
Q: What are the efficiency ratings of this UPS?
A: The UPS operates at up to 94% efficiency in double-conversion mode and up to 97% in ECO mode.
