Elevate your computing experience with the AMD Ryzen 7 7700X AM5 Processor. Engineered with 8 cores and 16 threads, this processor delivers robust performance, boasting a max boost clock of up to 5.4 GHz. Built on the 5nm 'Zen 4' architecture, it's designed for modern systems seeking high-speed processing and efficiency.
Key Features at a Glance
- 8 Cores & 16 Threads for advanced multitasking
- Max boost clock of up to 5.4 GHz and 40 MB Cache
- Built on efficient 5nm 'Zen 4' Architecture
- Compatible with Socket AM5 motherboards and 600 Series Chipset
- Supports DDR5 5200MHz memory and PCIe Gen 5.0
- Features AMD EXPO Technology and AMD Ryzen Technologies
Unleash Powerful Performance
Experience exceptional speed and responsiveness with 8 cores, 16 threads, and a formidable 40 MB cache. This processor maintains a base clock of 4.5 GHz, dynamically boosting up to 5.4 GHz for demanding applications and gaming.
Next-Generation Architecture
Leverage the advanced 5nm 'Zen 4' architecture, designed for superior power efficiency and performance. The AMD Ryzen 7 7700X integrates the latest technologies, including support for DDR5 5200MHz memory across 2 channels and PCIe Gen 5.0, enabling a high-bandwidth platform.
Seamless Compatibility & Features
Engineered for the future, this processor is fully compatible with Socket AM5 motherboards utilizing the 600 Series Chipset. Benefit from AMD EXPO Technology for optimized memory overclocking and other innovative AMD Ryzen Technologies for an enhanced user experience.
Technical Specifications
| Platform | Desktop |
| Market Segment | Enthusiast Desktop |
| Product Family | AMD Ryzen™ Processors |
| Product Line | AMD Ryzen™ 7 Desktop Processors |
| AMD PRO Technologies | No |
| Consumer Use | Yes |
| Regional Availability | Global |
| Former Codename | "Raphael AM5" |
| Architecture | "Zen 4" |
| of CPU Cores | 8 |
| Multithreading (SMT) | Yes |
| of Threads | 16 |
| Max. Boost Clock | Up to 5.4GHz |
| Base Clock | 4.5GHz |
| L1 Cache | 512KB |
| L2 Cache | 8MB |
| L3 Cache | 32MB |
| Default TDP | 105W |
| Processor Technology for I/O Die | TSMC 6nm FinFET |
| CPU Compute Die (CCD) Size | 71mm² |
| I/O Die (IOD) Size | 122mm² |
| Package Die Count | 2 |
| Unlocked for Overclocking | Yes |
| AMD EXPO™ Memory Overclocking Technology | Yes |
| Precision Boost Overdrive | Yes |
| Curve Optimizer Voltage Offsets | Yes |
| AMD Ryzen™ Master Support | Yes |
| CPU Socket | AM5 |
| Supporting Chipsets |
A620 |
| CPU Boost Technology | Precision Boost 2 |
| Instruction Set | x86-64 |
| Supported Extensions | AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
| Thermal Solution (PIB) | Not included |
| Max. Operating Temperature (Tjmax) | 95°C |
| OS Support |
|
| Connectivity | |
| USB Type-C® Support | Yes |
| Native USB 3.2 Gen 2 (10Gbps) Ports | 4 |
| Native USB 3.2 Gen 1 (5Gbps) Ports | 0 |
| Native USB 2.0 (480Mbps) Ports | 1 |
| Native SATA Ports | 0 |
| Native PCIe® Lanes (Total/Usable) | 28/24 |
| Additional Usable PCIe Lanes from Motherboard |
AMD X670E 12x Gen4 AMD X670 12x Gen4 AMD B650E 8x Gen4 AMD B650 8x Gen4 |
| NVMe Support | Boot, RAID0, RAID1, RAID10 |
| Memory Channels | 2 |
| Max. Memory | 128GB |
| System Memory Subtype | UDIMM |
| Max Memory Speed |
1x1R 5200 MT/s 1x2R 5200 MT/s 2x1R 3600 MT/s 2x2R 3600 MT/s |
| ECC Support | Yes (Requires mobo support) |
| Graphics Capabilities | |
| Integrated Graphics | Yes |
| Graphics Model | AMD Radeon™ Graphics |
| Graphics Core Count | 2 |
| Graphics Frequency | 2200 MHz |
| USB Type-C® DisplayPort™ Alternate Mode | Yes |
| Product ID Boxed | 100-100000591WOF |
| Product ID Tray | 100-000000591 |
| Key Features | |
| Supported Technologies |
|
| Warranty | 3 Years |
Frequently Asked Questions
Q: What is the core and thread count of the AMD Ryzen 7 7700X?
A: The AMD Ryzen 7 7700X processor features 8 cores and 16 threads, providing ample processing power for multitasking and demanding applications.
Q: What motherboards are compatible with this processor?
A: This processor is compatible with motherboards based on the 600 Series Chipset and designed for the Socket AM5 platform.
Q: What memory standard does the Ryzen 7 7700X support?
A: The AMD Ryzen 7 7700X supports DDR5 5200MHz memory and utilizes 2 memory channels.
