Feature Highlights


- Powered by the NVIDIA Blackwell architecture and DLSS 4
- 8-Pin PCIe power connector
- SFF-Ready compact Graphics Card
- Blade Link Fans
- All-new Fire Storm Utility
- 3 years Warranty + Additional 2 years after Registration



Specifications



Specification Details
Graphics Processor NVIDIA GeForce RTX 5060 GPU
CUDA Cores 3840
Video Memory 8GB GDDR7
Memory Bus 128-bit
Graphics Processor Frequency 2550 MHz
Memory Frequency 28 Gbps
PCI Express PCI Express 5.0 x8
Display Outputs 3x DisplayPort 2.1b with UHBR20 1x HDMI 2.1b
Max Display Resolutions Up to 4K @ 480Hz or 8K @ 165Hz (with DSC)
HDMI Support 4K @ 480Hz HDR or 8K @ 120Hz HDR with DSC, Gaming VRR (HDMI 2.1b spec)
HDCP Support 2.3
Multi-Screen Support Quad Display
Recommended PSU 600W
Power Consumption 155W
Power Connectors 1x 8-pin power input
DirectX Support Microsoft DirectX® 12 Ultimate
OpenGL Support 4.6
Cooling Air Cooled
Slot Width 2-slot
SLI Support No
Operating System Compatibility Windows 11 / Windows 10 64-bit (v1809 November 2018 or later)
Dimensions (L x W x H) 220.5 x 120.25 x 41.6 mm (8.7" x 4.7" x 1.6")
Accessories User Manual
