ARCTIC P14 PWM PST (BLACK) ACFAN00125A
If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, within 24 hours on weekdays.
-
Shipping Information
Use this text to answer questions in as much detail as possible for your customers.
-
Customer Support
Use this text to answer questions in as much detail as possible for your customers.
-
FAQ’s
Use this text to answer questions in as much detail as possible for your customers.
-
Contact Us
Use this text to answer questions in as much detail as possible for your customers.
The ARCTIC P14 PWM PST (BLACK) fan, model ACFAN00125A, provides a core component for your system. This black fan is designed with specific features, detailed further in the technical specifications below.
Key Features at a Glance
- ARCTIC brand design
- P14 fan model
- Features PWM Technology
- Includes PST (PWM Sharing Technology)
- Sleek black finish
- Model number ACFAN00125A
Integrated PWM Control
This ARCTIC fan incorporates PWM (Pulse Width Modulation) technology, as indicated in its product name. For specific details on its operation and capabilities, please consult the technical specifications.
PST for Enhanced Connectivity
The PST (PWM Sharing Technology) feature of this fan is identified by its model. Further information on how this technology functions can be found in the comprehensive technical specifications.
Coordinated Aesthetics
Sporting a black color, this ARCTIC P14 fan offers a neutral aesthetic that can integrate into various system builds. Its design is consistent with the product's defined characteristics.
Technical Specifications
| P14 PWM PST — Combined Specifications | |
|---|---|
| Product Name | P14 PWM PST — 140 mm PWM Fan with Cable Splitter |
| Model / SKU | ACFAN00125A |
| Dimensions | 140 × 140 × 27 mm |
| Weight | 194 g |
| Speed | 200–1700 rpm (0 rpm < 5% PWM) |
| Speed Control | PWM (Pulse Width Modulation) |
| Static Pressure | 2.40 mmH₂O |
| Airflow | 72.8 cfm | 123.80 m³/h |
| Bearing | Fluid Dynamic Bearing |
| Cable Length | 400 mm |
| Connector Type | 4-Pin Connector + 4-Pin Plug (PST) |
| Current / Voltage | 0.12 A / 12 V DC |
| Starting Voltage | 3.9 V DC |
| Noise Level | 0.3 Sone |
| Operating Temperature | 0 – 40 °C |
| Packaging Details | |
| Standard Box Dimensions | 143 × 143 × 29 mm |
| Standard Box Weight | 235 g |
| Standard SKU | ACFAN00125A |
| Standard EAN / UPC | EAN: 4895213701563 | UPC: 872767009509 |
| Standard Box Contents | P14 PWM PST × 1, Mounting screws × 4 |
| Black Version SKU | ACFAN00197A |
| Black Version EAN / UPC | EAN: 4895213703116 | UPC: 840033400916 |
| Value Pack (5-Pack) SKU | ACFAN00138A |
| 5-Pack Dimensions | 145 × 139 × 146 mm |
| 5-Pack Weight | 960 g |
| 5-Pack EAN / UPC | EAN: 4895213701600 | UPC: 872767009547 |
| 5-Pack Contents | P14 PWM PST × 5, Mounting screws × 20 |
| Pinout | |
| Pin 1 | Ground (−) |
| Pin 2 | Power (+) |
| Pin 3 | Signal (Tachometer) |
| Pin 4 | PWM Control |
Frequently Asked Questions
Q: What is the full product name of this item?
A: The full product name is ARCTIC P14 PWM PST (BLACK).
Q: What is the model number for this ARCTIC fan?
A: The model number is ACFAN00125A.
Q: Does this fan include PWM Sharing Technology (PST)?
A: Yes, this ARCTIC P14 fan is specified to include PST (PWM Sharing Technology).
