Features GIGABYTE B760M D2H DDR4 Intel Motherboard

• Intel® Socket LGA 1700：Support 13th and 12th Gen Series Processors
• Unparalleled Performance： Hybrid 6+2+1 Phases Digital VRM Solution
• GIGABYTE B760M D2H DDR4：2*DIMMs XMP Memory Module Support
• Next Generation Storage：2*PCIe 4.0 x4 M.2 Connectors
• EZ-Latch： PCIe 4.0×16 Slot with Quick Release Design
• Fast Networks：2.5GbE LAN
• Extended Connectivity： HDMI, D-Sub
• Smart Fan 6：Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
• Q-Flash Plus： Update BIOS Without Installing the CPU, Memory, and Graphics Card

Performance

6+2+1 Phases Hybrid Digital VRM Design, 6+2+1 Phases Low RDS(on) MOSFETs, Premium Choke and Capacitors to improve transient response and minimize oscillation

GIGABYTE B760 Motherboards are ready to work with the PCIe 4.0 devices which are expected to experience triple bandwidth than the current PCIe 3.0 devices. To reach the high speed and maintain good signal integrity, GIGABYTE R&D uses the low impedance PCB to provide the maximum performance.

DR5 Auto Booster

Automatically Boost the Native DDR4 frequency to 5000MHz while the system is under heavy loading by a single click

DR5 Memory Upgrade

GIGABYTE BIOS offers pre-defined and retrievable profiles for users to get higher performance easily. The profiles are based on a database that is created by checking each memory IC and PMIC vendors to optimize the modules to unleash their full potential. This is a time saving feature to manually configure overclocked DDR4 memory kits.

Instantly upgrade memory performance

• Overclock Native and XMP 3.0 DDR4 memory to higher frequency easily
• No need to input dozens of memory parameters such as clock, voltage and timings
• Built-in wide variety pre-tuned profiles database for different memory IC vendors

XMP 3.0 User Profile

• Define and create your own SPD profile into Native and XMP 3.0 memory modules or apply the pre-tuned profiles to XMP 3.0 User Profile. Two user-defined profiles can be saved, loaded either locally or from/to an external storage device.
• Two empty SPD profiles can be defined by users and carry to next computer
• Transfer DDR4 XMP Booster profiles into XMP 3.0 User Profiles
• Quick memory performance simulation based on user input clock and timing parameters
• Profile save and load function to share your memory parameters online

DDR4 Overclocking Up to 8000 and Beyond

Gigabyte is offering a tested and proven platform that has memory overclocking capability up to 8000 and beyond. For DDR4 XMP Memory, all users need to do to attain high memory performance boost is to ensure that their memory module is XMP capable and that the XMP function is activated and enabled on their GIGABYTE motherboard

CONNECTIVITY

• GIGABYTE Motherboards enable the ultimate connection experience with blazing data-transfer speeds through the next generation network and storage
• Friendly User Interface
• The EASY MODE shows important hardware information in one page including CPU clock, Memory, Storage, Fan.

My Favorites

• Add constantly used items into the favorite menu for quick access.
• Storage Information
• Show all kinds of storage information including SATA, PCIE and M.2 interface.

Changelog

• List all changes before saving and exiting bios. Quickly review overall settings modification.
• Intuitive Load Line Curve
• Clearly show each loadline calibration setting in an intuitive curve graph

PCIe EZ-Latch

Unlock the latch of the PCIe slot easily when remove the graphics card in the PCIe slot

GIGABYTE PerfDrive

PerfDrive technology integrates multiple GIGABYTE exclusive BIOS settings to allow users to balance between different levels of performance, power consumption, and temperature according to their needs easily when using 13th gen Intel® Core™ processors

Smart Fan 6 BIOS UI

1 Improve fan curve UI

We increase control points from 5 to 7 and larger fan speed graph for precise and easier fan curve control.

2 Slope/Stair dual graph mode

Fan curve can be quickly switch with Slope and Stair modes for different user scenario. Slope is traditional and intuitive linear fan speed curve. With newly added Stair non-linear mode, fan keeps at same speed between specified temperature interval.

3 Manual Input

For advanced users, we provide fan speed manual input for more precise control.

4 EZ Tuning

Use can place 4 EZ Tuning points at rough temperature/fan speed, and Smart Fan 6 can quickly generate a fan curve.

5 Fan curve profile

Fan curve profile can be saved in BIOS ROM, profile will be kept after updating BIOS.
Note: The picture is for reference and may vary by model.

SMART FAN 6

Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool and quiet. Multiple fan headers can support PWM/DC fan and pump, and users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface.

Cooling Features

• High Current Support: Each fan headers support PWM and DC fan and Water Cooling Pump , and up to 24W (12V x 2A) with Over-Current Protection
• Precision Control: Multiple temperature/fan speed control points for precise fan curve
• Dual Curve Mode: Slope/Stair dual mode for different user scenario
• Fan Stop: Fan can stop completely below users’ specified temperature point

Specifications GIGABYTE B760M D2H DDR4 Intel Motherboard
