Features of FRACTAL DESIGN Lumen S36 360mm CPU Liquid Cooler (Black)



Customize your water-cooling from subtle to stunning with Lumen’s six addressable LEDs that you can command via motherboard or controller. Compatible with most common Intel/AMD sockets and RGB certified by industry standards, the Lumen is an attractive proposition for starting and seasoned builders alike.

  1. Duality design provides both a stealthy and illuminated look, controlled from your motherboard RGB UI
  2. Six ARGB LEDs are yours to command via your motherboard or controller
  3. The removable top can be turned at 90-degree intervals, making the logotype horizontal independent of the mounting orientation
  4. Pre-applied thermal paste ensures an easy installation
  5. Supports the most common sockets for both Intel and AMD
  6. Aspect fans for low turbulence and chaining support
  7. Articulating elbow fittings make tubes easier to route and reduces tension on the cold plate housing
  8. Current certifications include Asus AURA, Gigabyte Fusion, MSI Mystic Light, Razer Chroma and ASRock Polychrome support
  9. Low-permeability rubber tubes with braided nylon sleeves

The right way up

  • The removable top can be turned at 90-degree intervals, making the logotype horizontal independent of the mounting orientation
  • Low-permeability rubber tubes with braided nylon sleeves

From subtle to stunning

  • Duality design provides both a stealthy and illuminated look, controlled from your motherboard RGB UI
  • Six ARGB LEDs are yours to command via your motherboard or controller

Forget the thermal paste

  • Thermal paste is pre-applied to ensure a proper and pain-free installation
  • Articulating elbow fittings make tubes easier to route and reduces tension on the cold plate housing

Common denominators

  • Compatible with LGA 1700
  • Supports the most common sockets for both Intel and AMD



Specifications of FRACTAL DESIGN Lumen S36 360mm CPU Liquid Cooler (Black)



General specifications
Sockets supported (Intel) LGA 1150/1151/1155/1156/1200 LGA 1366/2011/2011-3/2066
Sockets supported (AMD) AM4/FM2+/FM2/ FM1/AM3+/AM3/AM2+/AM2
Cold plate material Copper
Thermal paste Pre-applied
Tube length 400mm
Tube material Low-permeability rubber with braided nylon sleeve
Fittings, block side Articulating 90-degree Elbow
Fittings, radiator side Barbed fitting
Block height 43mm
Block measurements (with fittings) 79 x 67 mm
Block diameter (main block body) 67 mm
Fan specifications
Fan type Aspect 12 PWM
Rotational speed 500–2000 RPM
Fan bearing Rifle bearings
Fan PWM control Yes
Fan acoustical noise <10–33.2 dBA
Fan maximum air flow 13-56 CFM
Fan maximum static pressure 0.230–2.34 mm H2O
Fan input voltage 12V
Fan maximum input current 0.37A
Fan MTTF 90,000 hours
Pump specifications
Rotational speed 4000 ± 10% RPM
Bearing type Ceramic
PWM control No
Acoustical noise (full speed) 22 dBA
Maximum pressure 1.8 mm H2O/ 17.6 kPa / 2.5 PSI
Input voltage 12V DC
Input current (without fans) 0.34 A
MTTF 50 000 hours
Radiator specifications
Radiator dimensions 392 x 120 x 27 mm
Radiator housing material Aluminum
Radiator fin material Aluminum
Radiator fan screw threads 6-32
Other
Package contents CPU Cooler Assembly, 3x Aspect 12 PWM fans, User manual, Intel mounting kit, AMD mounting kit, 5V ARGB cable
Package dimensions 448 x 205 x 137 mm
Package weight 2.20kg
Product Code FD-W-L1-S3601
