Features of Deco X55 AX3000
AX3000 Dual Band WiFi -
Super-fast WiFi 6 with speeds up to 3.0 Gbps
4 Streams, Less Lag -
2×2/HE160 2402 Mbps + 2×2 574 Mbps
Gigabit Wired Speed -
3× Gigabit ports provide sufficient connectivity
Boosted Seamless Coverage -
Seamless mesh WiFi coverage up to 4,500 ft2 (2-pack)
AI-Driven Mesh -
Intelligently learns the network environment to provide ideal WiFi unique to your home
TP-Link HomeShield -
Provides comprehensive network protection, robust parental controls, and real-time IoT protection
Setup Made Easier Than Ever -
The Deco app walks you through the setup step-by-step
Specifications of Deco X55 AX3000
| WIRELESS | |
| Standards |
Wi-Fi 6 IEEE 802.11ax/ac/n/a 5 GHz IEEE 802.11ax/n/b/g 2.4 GHz |
| WiFi Speeds |
AX3000 5 GHz: 2402 Mbps (802.11ax, HE160) 2.4 GHz: 574 Mbps (802.11ax) |
| WiFi Range |
3-4 Bedroom Houses (2-pack)TP-Link Mesh Technology
Optional Ethernet backhaul work together to link Deco units to provide seamless coverage AI-Driven Mesh 2× Antennas (Internal) Beamforming |
| WiFi Capacity |
HighDual-Band
Distribute devices to different bands for optimal performance 2×2 MU-MIMO OFDMA 4 Streams |
| Working Modes |
Router Mode Access Point Mode |
| HARDWARE | |
| Button | Reset Button |
| Ethernet Ports |
3× Gigabit Ports
*Per Deco Unit |
| SECURITY | |
| WiFi Encryption |
WPA-Personal WPA2-Personal WPA3-Personal |
| Network Security |
SPI Firewall Access Control HomeShield SecurityReal-Time IoT Protection |
| Guest Network |
1× 5 GHz Guest Network 1× 2.4 GHz Guest Network |
| SOFTWARE | |
| Protocols |
IPv4 IPv6 |
| Service Kits | HomeShield |
| Parental Controls |
HomeShield Parental ControlsCustom Profiles Professional Content Filter Library Family Time Bedtime Off Time Time Rewards Family Online Time Ranking Pause the Internet Weekly and Monthly Reports |
| WAN Types |
Dynamic IP Static IP PPPoE PPTP L2TP |
| Quality of Service | HomeShield QoSQoS by Device |
| Cloud Service |
OTA Firmware Upgrade TP-Link ID DDNS |
| NAT Forwarding |
Port Forwarding UPnP |
| IPTV |
IGMP Proxy IGMP Snooping Bridge Tag VLAN |
| DHCP |
Address Reservation DHCP Client List Server |
| DDNS | TP-Link |
| Management | Deco App |
| TEST DATA | |
| WiFi Transmission Power |
CE: <20 dBm (2.4 GHz) <23 dBm (5 GHz) FCC: <30 dBm (2.4 GHz) <30 dBm (5 GHz) |
| PHYSICAL | |
| Dimensions (W×D×H) |
4.33 × 4.33 × 4.49 in (110 × 110 × 114 mm) |
| Package Contents |
Deco X55 (1-pack) 1 Deco X55 unit 1 RJ45 Ethernet cable 1 Power adapter 1 Quick Installation Guide Deco X55 (2-pack) Deco X55 (3-pack) |
| OTHERS | |
| System Requirements |
Android 5.0 or later
iOS 9.0 or later *Note: The minimum system requirements will be updated alongside updates to the app, subject to official website information. |
| Certifications | CE, FCC, RoHS, RCM |
| Environment |
Operating Temperature: 0°C~40°C (32°F~104°F) Storage Temperature: -40°C~70°C (-40°F~158°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
