ASROCK TRX40 Creator DDR4 AMD Motherboard

360˚

- 52%

Motherboard

ASROCK TRX40 Creator DDR4 AMD Motherboard

Rs. 90,900.00 Rs. 43,495.00

Availability : Out Of Stock

Brand : ASROCK

SKU : Asrock-trx40-creator

Tags : ASROCK, CATP_ASROCK, CATQ_Motherboard, MOB10_ARGB, MOB11_5, MOB12_0, MOB13_Gen4, MOB14_Gen4, MOB15_White, MOB16_1, MOB17_8, MOB18_6, MOB19_1, MOB1_TRX40, MOB20_2, MOB21_2, MOB22_0, MOB23_75, MOB24_AMD Motherboard, MOB2_ATX, MOB3_sTRX4, MOB4_256, MOB5_4666, MOB6_8, MOB7_DDR4, MOB8_3, MOB9_0

Safe Payment

Pay with the world’s most payment methods.

Confidence

Protection covers your purchase

Worldwide Delivery

Ship to over 200 countries & regions.

Hotline

+91-99250 02827

Description

Feature of ASROCK TRX40 Creator DDR4

The Asrock TRX40 Creator Motherboard has 128Mb AMI UEFI Legal BIOS with GUI support. Asrock TRX40 Creator Motherboard has XXL Aluminum Alloy Heatsink & Heat pipe Design. The hardware monitors the temperature, Fan Tachometer, quite a fan control, voltage. Asrock TRX40 Creator Motherboard has a superior 90A Power Choke. Not only visual satisfaction is necessary but also audio! Get the best hypnotic sounds with 7.1 CH HD Audio to feel like a pro! Along with all this, the Asrock TRX40 Creator Motherboard Also comes with a complete warranty of three whole years!

Supports 3rd Gen AMD Ryzen™ Threadripper™ Processors
8 Power Phase Design, 90A Dr. MOS & Power Choke
XXL Aluminum Alloy Heatsink & Heatpipe Design
Supports DDR4 4666+(OC)
4 PCIe 4.0 x16
NVIDIA® NVLINK™, 4-Way SLI™, AMD 4-Way CrossFireX™
8 SATA3, 2 Hyper M.2 (PCIe Gen4 x4), 1 Hyper M.2 (PCIe Gen4 x4 & SATA3)
1 Rear USB 3.2 Gen2 x2 20Gb/s Type-C
3 USB 3.2 Gen2 (1 Front Type-C, 2 Rear)
8 USB 3.2 Gen1 (4 Front, 4 Rear)
7.1 CH HD Audio (Realtek ALC4050H+ALC1220), Supports Purity Sound™ 4 & DTS Connect
AQUANTIA® 10G LAN, Realtek 2.5G LAN
Intel® Wi-Fi 6 802.11ax (2.4Gbps) + BT 5.0

Wi-Fi 6 802.11ax

Welcome to the new Wi-Fi standard! ASRock’s motherboard equipped with next generation Intel^® Wi-Fi 6 802.11ax adapter. The speed will be working up to 2.4Gbps and it will also natively operate with both 2.4Ghz and 5Ghz simultaneously. Significant improvement in bi-directional MU-MIMO support is another attractive feature as well.

Separated CPU Power Connector Design

Unlike traditional dual CPU power connectors which are located closely together at the same side, ASRock separates them to either side of motherboard in order to create wider trace for CPU VRM. This design brings better power delivery efficiency and lower temperature, thus improving system stability and increasing overclocking potential.

USB 3.2 Gen2x2 Type-C

The latest USB 3.2 Gen2x2 Type-C delivers up to 20 Gbps data transfer rate which is 2x as fast as previous generation, providing a blazing fast data transfer interface with reversible USB Type-C design that fits the connector either way.

AQUANTIA^® 10Gb/s BASE-T Ethernet

The new 10Gb/s network standard was specially designed to satisfy the user who is seeking immediate performance improvements. Based on AQUANTIA's AQtion™ client controller, it offers blazingly fast 10-gigabit/sec transfer speed over Cat6 cable. The 10Gb/s Ethernet not only fully compatible with 5Gb/s, 2.5Gb/s & Gigabit Lan but also delivers lightning fast transfer speed, perfect for media center, workstation and gaming PC.

STEEL SLOT WITH NEW-GEN PCI EXPRESS 4.0

The next generation PCI Express 4.0 is capable of performing twice the speed compared to previous 3rd generation. ASRock’s exclusive Steel Slot with extra anchor points are revolutionary added to ensure signal stability and also making sure heavy graphics cards to be well-installed in the PCI-E slot safely.

8LAYER & 2OZ COPPER PCB

The 8 Layer PCB comes with 4 sets of 2 ounce copper inner layers, providing stable signal traces and power shapes and delivering lower temperature and higher energy efficiency for overclocking! Thus, it's able to support the latest DDR4 memory modules with most extreme memory performance!

Server-Grade Low-Loss PCB

The server grade PCB prevents PCB bending and improves signal integrity, giving higher PCIe 4.0 and memory performance as well as system stability, giving a reliable and long-

AMD StoreMI Technology

A powerful tool that combines the speed of your SSD with the capacity of your hard disk into a single, fast, easy-to-manage drive, “combines” these two types of storage into a single drive and automatically moves the data you access the most to the SSD, so you get the best of both worlds.

Specifications of ASROCK TRX40 Creator DDR4

Brand	ASRock
Model	TRX40 Creator
CPU Socket Type	sTRX4
CPU Type	Supports 3rd Gen AMD Ryzen Threadripper Processors
South Bridge	N/A
Number of Memory Slots	8 x DIMM
Memory Standard	Supports DDR4 4666(OC)+ / 4600(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 /
Maximum Memory Supported	256GB, DDR4
Channel Supported	Quad channel
PCI Express x16	4
PATA	N/A
SATA 3Gb/s	8 x SATA 6Gb/s
SATA RAID	0,1,10
Onboard Video Chipset	N/A
Audio Channels	7.1 CH HD Audio
Max LAN Speed	1 x 2.5 Gigabit LAN 10/100/1000/2500 Mb/s
LAN Chipset	AQUANTIA 10G LAN, Realtek 2.5G LAN
PS/2	1
Audio Ports	5
Onboard USB	6 x USB
Onboard 1394	N/A
Form Factor	ATX
Power Pin	24 Pin
